Danfoss REG-SA SS 15 straightway stainless hand regulating valve, butt weld EN 10220, cap, 1/2 in (15 mm), 52 bar (code 148B5298)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss REG-SA SS 15 straightway stainless steel hand-operated regulating (throttling) valve for industrial-refrigeration line service, code 148B5298. REG-SA carries the A-cone for fine, near-linear throttling; the SS designation is the stainless-steel body for improved corrosion resistance on CO2 (R744) and ammonia (R717) duty. This straightway body carries butt-weld inlet and outlet to EN 10220, size 1/2 in (15 mm) — distinct from the angleway EN REG-SA SS 15 (148B5297) and the straightway ASME Schedule 40 REG-SA SS 15 (148B5299). Regulating cone with spindle scale and vented cap (hand wheel optional); maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F); Kv 1.5 m3/h (Cv approx 1.7 gal/min). Straightway body places inlet and outlet in line.
Specifications
- Part number
- 148B5298
- HS code
- 8481.80
- Material
- Stainless steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard size
- 1/2 in (15 mm)
Compatibility
Danfoss REG-SA SS Flexline stainless hand regulating valve, straightway EN 10220 butt-weld variant. Select by cone (SA = lower-Kv A-cone, SB = higher-Kv B-cone), nominal size (DN15 / 1/2 in), direction and connection standard. The EN 10220 and ASME Sch40 bodies are separate codes — confirm cone, direction and pipe connection before ordering.
Approvals
