Danfoss RA-KE/KEW single-pipe manifold valve body, straight
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss RA-KE/KEW manifold assembly, OEM order code 013G3362 — a bare RA-KE/KEW manifold valve body (straight, single-pipe) without an integral return lockshield — it takes a Danfoss RA-series thermostatic sensor or actuator on its clamp connection to throttle the radiator. Used to connect radiators to one-pipe (RA-KE/KEW) or two-pipe (RA-K/KW) Danfoss distribution manifolds. Connection G 1/2 on the manifold side and R 1/2 on the radiator side, straight pattern. Kvs 2.5 m³/h; max working pressure 10 bar (test 16 bar), max differential pressure 0.6 bar, flow temperature up to 120 °C. Brass. Genuine Danfoss part; technical data quoted verbatim from store.danfoss.com (code 013G3362). OEM P/N 013G3362, EAN 5702420031781. HS 8481.80.
Technical Specifications
- Brand
- Danfoss
- Part number
- 013G3362
- Type
- RA-KE/KEW
- Product group
- Manifold Assemblies
- Application
- 1-pipe system
- Valve type
- RA-KE with elbow
- RLV (return lockshield) type
- no RLV
- Design
- Straight
- Connection size (manifold side)
- G 1/2
- Connection size (radiator side)
- R 1/2
- Contents of set
- Valve
- Kvs value
- 2.5 m³/h
- Differential pressure (max)
- 0.6 bar
- Flow temperature (max)
- 120 °C
- Working pressure (max)
- 10 bar
- Test pressure
- 16 bar
- Feature description
- RA-KE Valve body
- REACH candidate-list substances
- Lead (CAS no. 7439-92-1)
- EU RoHS compliance
- Yes with exemptions
- Net weight
- 0.374 Kilogram
- Gross weight
- 0.374 Kilogram
- Packed volume
- 0.343 Liter
- EAN
- 5702420031781
- HS code
- 8481.80 (taps, cocks, valves for pipes, tanks, vats or the like)
Standards & Compliance
- Material
- Body brass
- Pressure Rating
- 10 bar max working (test 16 bar)
- Temperature Range
- up to 120 °C (flow)
- HS Code
- 8481.80
Compatibility & Fitment
Single-pipe radiator manifold valve body for the Danfoss RA-K/RA-KE system, straight pattern, G 1/2 manifold connection / R 1/2 radiator connection. Accepts a Danfoss RA-series thermostatic sensor or thermal/electric actuator on the valve clamp ring. Confirm the system type (1-pipe system), connection pattern (Straight) and variant (RA-KE/KEW) against the installation before ordering.
