Danfoss RA-K/KW two-pipe manifold valve body, straight

Danfoss RA-K/KW manifold assembly, OEM order code 013G3363 — a bare RA-K/KW manifold valve body (straight, two-pipe) without an integral return lockshield — it takes a Danfoss RA-series thermostatic sensor or actuator on its clamp connection to throttle the radiator. Used to connect radiators to one-pipe (RA-KE/KEW) or two-pipe (RA-K/KW) Danfoss distribution manifolds. Connection G 1/2 on the manifold side and R 1/2 on the radiator side, straight pattern. Kvs 0.76 m³/h; max working pressure 10 bar (test 16 bar), max differential pressure 0.6 bar, flow temperature up to 120 °C. Brass. Genuine Danfoss part; technical data quoted verbatim from store.danfoss.com (code 013G3363). OEM P/N 013G3363, EAN 5702420031798. HS 8481.80.

Brand

Danfoss

Part number

013G3363

Type

RA-K/KW

Product group

Manifold Assemblies

Application

2-pipe system

Valve type

RA-K with elbow

RLV (return lockshield) type

no RLV

Design

Straight

Connection size (manifold side)

G 1/2

Connection size (radiator side)

R 1/2

Contents of set

Valve

Kvs value

0.76 m³/h

Differential pressure (max)

0.6 bar

Flow temperature (max)

120 °C

Working pressure (max)

10 bar

Test pressure

16 bar

Feature description

RA-K Valve body

REACH candidate-list substances

Lead (CAS no. 7439-92-1)

EU RoHS compliance

Yes with exemptions

Net weight

0.322 Kilogram

Gross weight

0.332 Kilogram

Packed volume

0.33 Liter

EAN

5702420031798

HS code

8481.80 (taps, cocks, valves for pipes, tanks, vats or the like)

Material

Body brass

Pressure Rating

10 bar max working (test 16 bar)

Temperature Range

up to 120 °C (flow)

HS Code

8481.80
