Danfoss MBT 5252 temperature transmitter, Pt 100 to 4-20 mA, 250 mm insertion, G 1/2 process connection (code 084Z6143)
Danfoss · Sensors & Instrumentation · Temperature Sensors
Danfoss MBT 5252 heavy-duty temperature transmitter with exchangeable measuring insert, code 084Z6143 (type designation MBT 5252-0011-0250-0200-G110). Insertion sensor with a built-in two-wire head transmitter that converts a Pt 100 (EN 60751, Class B) input into a 4-20 mA output; used for cooling water, lubricating and hydraulic oil and refrigeration plant in general industry and marine installations. Insertion length 250 mm; G 1/2 male process connection; AISI 316 Ti stainless-steel protection tube, 10 mm diameter. Measuring range -50 to +200 C (-58 to +392 F). Supply voltage 8-35 V DC. Type B connection head, Pg 16; IP65 enclosure per IEC 60529. CE marked.
Specifications
- Part number
- 084Z6143
- HS code
- 9025.19
- Material
- AISI 316 Ti stainless steel
- Temperature range
- -50 to +200 C (-58 to +392 F)
- IP rating
- IP65
- Standard size
- 250 mm insertion
- Thread standard
- ISO 228-1-A
Compatibility
MBT 5252 insertion transmitter. Confirm insertion length (250 mm), process thread (G 1/2) and that the 4-20 mA output and 8-35 V DC supply suit the controller/DCS input. The measuring insert is field-replaceable.
Standards
- EN 60751
- ISO 228-1-A
- IEC 60529
Approvals
