Danfoss MBT 5252 heavy-duty temperature sensor, Pt 1000, 250 mm insertion, G 1/2, Type B head Pg 16 (code 084Z3281)
Danfoss · Sensors & Instrumentation · Temperature Sensors
Danfoss MBT 5252 temperature sensor, code 084Z3281 (type designation MBT 5252-0311-0250-0200-0000). Insertion RTD for process, industry and marine temperature measurement. Pt 1000 (1000 ohm at 0 C), exchangeable insert platinum element, Class B tolerance per EN 60751. Insertion length 250 mm; G 1/2 male (ISO 228-1-A) process connection; AISI 316 Ti stainless steel, 10 mm diameter. Measuring range -50 to +200 C (-58 to +392 F); resistance (ohm) output, 2-wire; Type B connection head, Pg 16; IP65 enclosure per IEC 60529. Supplied in a 6-piece multipack. CE marked.
Specifications
- Part number
- 084Z3281
- HS code
- 9025.19
- Material
- AISI 316 Ti stainless steel
- Temperature range
- -50 to +200 C (-58 to +392 F)
- IP rating
- IP65
- Standard size
- 250 mm insertion
- Thread standard
- ISO 228-1-A
Compatibility
Confirm the insertion length (250 mm), process thread and electrical connector suit the installation, and that the element/output matches the receiving instrument.
Standards
- EN 60751
- ISO 228-1-A
- IEC 60529
Approvals
