Danfoss KP36 pressure switch, 1–10.5 bar, manual (max) reset, SPDT, G 1/2
Danfoss · Sensors & Instrumentation · Pressure Switches
Danfoss KP36 single-pressure switch (code 060-216066) with manual maximum reset. Regulating range 1–10.5 bar, fixed differential 0.7 bar, SPDT snap-action contact. G 1/2 male connection per ISO 228-1, IP30 enclosure, ambient -40 to +65 °C. Max test pressure 22 bar. Manual reset version for high-pressure cut-out and safety limiting of non-aggressive liquids and gases.
Specifications
- Part number
- 060-216066
- HS code
- 9026.20
- Material
- Steel/zinc-plated housing; bellows pressure element
- Pressure rating
- max test 22 bar
- Temperature range
- -40 to +65 °C (80 °C max 120 min)
- IP rating
- IP30 (IP55 with enclosure 060-033066/062866)
- Thread standard
- ISO 228-1 (G 1/2 male)
Compatibility
Manual-reset (max) version for high-pressure cut-out / safety limiting; the switch latches on trip and requires manual reset. SPDT contact. IP30 as supplied; IP55 with enclosure 060-033066/062866. Distinct code from the auto-reset KP36 (060-215966) — verify reset type before ordering.
Standards
- ISO 228-1 (G 1/2 connection)
- IEC 60529 (IP30)
- EU RoHS
Approvals
