Danfoss KP36 pressure switch, 1–10.5 bar (14.5–150 psig), 0.7 bar (10 psi) differential, manual maximum reset, SPDT, NPT 1/4-18, IP30
Danfoss · Sensors & Instrumentation · Pressure Switches
Danfoss KP36 pressure switch, code 060-214566. Regulation range 1–10.5 bar (14.5–150 psig) with 0.7 bar (10 psi), fixed differential and manual maximum reset, SPDT snap-action contact system. Pressure connection NPT 1/4-18 (female); swivel cable connector, NPSM 1/2-14 electrical entry; IP30 enclosure. Max working pressure 17 bar (245 psig). Bellows/diaphragm sensing element. EAN 5702423228867.
Specifications
- Part number
- 060-214566
- HS code
- 9026.20
- Material
- Steel/zinc-plated housing; bellows pressure element
- Pressure rating
- max working pressure 17 bar (245 psig)
- Temperature range
- -40 to +70 °C
- IP rating
- IP30
- Thread standard
- NPT 1/4-18 (female)
Compatibility
Manual maximum-reset KP36 for refrigeration/AC and general pressure control.
Standards
- IEC 60529 (enclosure IP rating)
- EU RoHS
Approvals
