Danfoss KP35 pressure switch, 0.4–3.5 bar, auto reset, SPDT, G 1/2
Danfoss · Sensors & Instrumentation · Pressure Switches
Danfoss KP35 single-pressure switch (code 060-216666). Regulating range 0.4–3.5 bar, differential 0.4–2.2 bar, automatic reset, SPDT snap-action contact. G 1/2 male connection per ISO 228-1, IP30 enclosure, ambient -40 to +65 °C. Max working pressure 17 bar, max test pressure 22 bar. For pressure monitoring and limiting of non-aggressive liquids and gases.
Specifications
- Part number
- 060-216666
- HS code
- 9026.20
- Material
- Steel/zinc-plated housing; bellows pressure element
- Pressure rating
- PB 17 bar; max test 22 bar
- Temperature range
- -40 to +65 °C (80 °C max 120 min)
- IP rating
- IP30 (IP55 with enclosure 060-033066/062866)
- Thread standard
- ISO 228-1 (G 1/2 male)
Compatibility
Single-pressure switch for monitoring/limiting of non-aggressive media. SPDT contact wired NO or NC. IP30 as supplied; fit top cover 060-109766 or IP55 enclosure 060-033066/062866 for higher ingress protection. Verify range/differential against the set point before ordering.
Standards
- ISO 228-1 (G 1/2 connection)
- IEC 60529 (IP30)
- EU RoHS
Approvals
