Danfoss ICS 100 pilot-operated servo valve, butt weld 4 in (100 mm), ASME B 36.10M Sch 40, steel, Kv 142 m³/h
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ICS 100 pilot-operated servo main valve (code 027H7121) for industrial refrigeration. Straightway steel body with butt-weld connections both ends, 4 in / 100 mm to ASME B 36.10M Schedule 40; flow coefficient Kv 142 m³/h (Cv 164.72 gal/min). The ICS main valve accepts up to three function modules on its top cover to set the control function (pilots ordered separately). Maximum working pressure 52 bar (754 psig); media temperature -60 to +120 °C (-76 to 248 °F). Suitable for R717 (ammonia), R744 (CO₂), HFC and hydrocarbon refrigerants. Specifications per Danfoss store code 027H7121.
Technical Specifications
- Type
- ICS 100 pilot-operated servo valve
- Code number
- 027H7121
- Size
- 100 mm (4 in)
- Direction
- Straightway
- Inlet/outlet connection
- Butt weld, steel, ASME B 36.10M Schedule 40
- Inlet/outlet connection size
- 4 in / 100 mm
- Kv value
- 142 m³/h (Cv 164.72 gal/min)
- Body material
- Steel
- Connection material
- Steel
- Surface coating
- Zn (TLP)
- Valve operation
- Pilot operated (accepts up to three function modules)
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to +120 °C (-76 to 248 °F)
- Refrigerants
- R717 (ammonia), R744 (CO₂), R134a, R404A, R410A and other listed refrigerants
- PED category
- II
- Approvals
- CE 0045, EAC (LLC CDC TYSK), TÜV, UL
- Compliance
- EU RoHS, China RoHS
- EAN
- 5702428229760
- Net weight
- 49.16 Kilogram
- Product group
- Press. and temp. regul. valves
- Approval
- CE 0045
- China RoHS compliance
- Yes
- Connection Code
- (2002:S40:100)
- Connection standard
- ASME B 36.10M SCHEDULE 40
- Cv value [gal/min]
- 164.72 gal/min
- Equipment
- Cap
- EU RoHS compliance
- Yes
- Ext pilot pressure connection
- Weld nipple (P2 Port)
- Flow direction indicator
- Embossed 1-way arrow
- Fluid Group
- 1
- Inlet connection size [in]
- 4 in
- Inlet connection size [mm]
- 100 mm
- Inlet connection type
- Butt weld
- Kv value [m³/h]
- 142 m³/h
- Manual operation option
- Manual open spindle
- Max. Working Pressure [bar]
- 52 bar
- Max. Working Pressure [psig]
- 754 psig
- Opening configuration
- Closed (delta p=0 bar)
- Outlet connection size [in]
- 4 in
- Outlet connection size [mm]
- 100 mm
- Outlet connection type
- Butt weld
- Pilot connection configuration
- P: Parallel connection
- Pressure gauge connection
- Int. thread with blind plug
- REACH Candidate List substances
- No
- Temperature range [°C] [max]
- 120 °C
- Temperature range [°C] [min]
- -60 °C
- Temperature range [°F] [max]
- 248 °F
- Temperature range [°F] [min]
- -76 °F
- Top cover
- 3 function modules
- UL approval file name
- REFRIGERANT VALVE 53R0
- UL mark
- Yes
- Valve version
- Standard version
Standards & Compliance
- Standard
- ASME B 36.10M Schedule 40
- Size / Series
- 100 mm (4 in)
- Material
- Steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to +120 °C
- HS Code
- 8481.80
Compatibility & Fitment
Danfoss ICS three-module servo main valve. Butt-weld variants dimensioned to EN 10220 (027H7120) and ASME B 36.10M Sch 40 (this code) are separate SKUs. Verify Kv, pilot/module configuration and refrigerant duty before ordering.
