Danfoss FIA 25 straightway strainer housing, socket weld ASME B 16.11, 1 in (25 mm), 52 bar

Danfoss FIA 25 straightway strainer (filter) housing for industrial-refrigeration line service, code 148B5448. The FIA housing takes a replaceable filter insert and removes particles from the refrigerant flow to protect downstream valves and controls. This straightway body carries socket weld inlet and outlet to ASME B 16.11, size 1 in (25 mm) — distinct from the EN 10220 and ASME butt-weld FIA 25 codes. Steel body; embossed one-way flow arrow; maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Supplied with cover. Suits HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems. The filter insert is ordered separately by mesh/micron rating.

Type

FIA 25 (strainer / filter housing)

Code number

148B5448

Series

FIA (Flexline strainers)

Function

In-line strainer housing (replaceable filter insert)

Nominal size

DN25 — 1 in (25 mm)

Direction

Straightway

Equipment

Cover

Flow direction

Embossed one-way arrow

Inlet connection type

Socket weld

Outlet connection type

Socket weld

Connection standard

ASME B 16.11

Connection size

1 in (25 mm)

Body material

Steel

Connection material

Steel

Maximum working pressure

52 bar (754 psig)

Media temperature range

-60 to 150 C (-76 to 302 F)

Applicable media

HCFC, HFC, R717 (ammonia), R744 (CO2)

CE mark

Yes

PED category

Art. 4, par. 3

Approvals

CE

Net weight

3 kg

EAN

5702428476430

Size / Series

1 in (25 mm)

Material

Steel

Pressure Rating

52 bar

Temperature Range

-60 to 150 C

HS Code

8421.39
