Danfoss AVQMT-WE motorized flow and temperature controller (PICV), PN 25, DN 25, flow range 0.2–4.5 m³/h, Kvs 8 m³/h, External thread G 1 1/4 A (ISO 228/1), via tailpieces

Danfoss AVQMT-WE (003H7087) — self-acting flow and temperature controller with integrated, pressure-independent motorized control valve (PICV); holds the differential pressure across the built-in flow restrictor constant so the electric actuator stem position sets flow independent of system pressure; limits the flow to the set maximum and closes on rising media temperature, PN 25, DN 25, for district heating and cooling systems. Because the built-in differential-pressure controller keeps the pressure drop across the flow restrictor constant, the flow becomes pressure-independent: the position of the separately ordered Danfoss AMV(E) electric actuator directly sets the flow, and the valve limits the flow to the set maximum and closes on rising media temperature via an AVT thermostatic actuator or STM safety temperature monitor fitted to the second connection neck. Flow range 0.2 - 4.5 m³/h; Kvs 8 m³/h; flow-restrictor differential pressure (Δpb) 0.2 bar; maximum differential pressure 16 bar; media temperature 2–150 °C; seat leakage 0.05 % Kvs (IEC 60534). Valve body Dezincification-resistant brass; stainless-steel seat/cone; EPDM control diaphragm. Connection External thread G 1 1/4 A (ISO 228/1), via tailpieces. Mounting version Free. Permissible media: district-heating/cooling circulation water (glycolic water up to 30 %), pH 7–10. The controller is delivered completely assembled, including the impulse tube between valve and actuator; the AMV(E) electric actuator and the AVT/STM thermostatic actuator are ordered separately. OEM P/N 003H7087. Materials and function per Danfoss AVQM-WE / AVQMT-WE (new neck) data sheet; technical values verbatim from store.danfoss.com (code 003H7087). Contains lead per the REACH candidate list. differential pressure 16 bar); Temperature range: 2 to 150 °C (district heating/cooling water); Standards: ISO 228-1, IEC 60534; HS code: 8481.80. Used in commercial refrigeration, provision-room cooling and reefer plant rooms across HFC, HFO and CO2 (R744) refrigerants.

Code number

003H7087

Type

AVQMT-WE

Product group

Pressure independent control valves (Pressure and flow controllers)

Function

Self-acting flow and temperature controller with integrated, pressure-independent motorized control valve (PICV); holds the differential pressure across the built-in flow restrictor constant so the electric actuator stem position sets flow independent of system pressure; limits the flow to the set maximum and closes on rising media temperature

Valve size

DN 25

Pressure class

PN 25

Connection

External thread G 1 1/4 A (ISO 228/1), via tailpieces

Kvs value

8 m³/h

Flow rate range

0.2 - 4.5 m³/h

Flow restrictor differential pressure (Δpb)

0.2 bar

Max. differential pressure

16 bar

Media temperature

2 - 150 °C

Media

District heating / district cooling circulation water (glycolic water up to 30%), pH 7 - 10

Seat leakage rate

0.05 % Kvs (IEC 60534)

Electric actuator

Danfoss AMV(E) (e.g. AMV/AME 110, 150, 435), ordered separately; controllable by ECL electronic controllers

Thermostatic actuator (temperature limiting)

Danfoss AVT thermostatic actuator or STM safety temperature monitor, ordered separately

Delivery

Delivered assembled, incl. impulse tube between valve and actuator; electric actuator ordered separately

Mounting version

Free

Valve body material

Dezincification-resistant brass

Valve seat / cone

Stainless steel

Control diaphragm

EPDM

EU RoHS compliance

Yes with exemptions (6(c))

REACH Candidate List substance

Lead (CAS no. 7439-92-1)

China RoHS

Out of scope

Net weight

3.75 kg

Gross weight

3.75 kg

EAN

5710104093987

Material

Valve body Dezincification-resistant brass; valve seat/cone Stainless steel; control diaphragm EPDM

Pressure Rating

PN 25 (max. differential pressure 16 bar)

Temperature Range

2 to 150 °C (district heating/cooling water)

HS Code

8481.80
