Danfoss AKS 3000 Pressure Transmitter 0–25 bar 4–20 mA — 060G1608
Danfoss · Sensors & Instrumentation · Pressure Transmitters
Danfoss AKS 3000 pressure transmitter, genuine OEM code 060G1608. Output 4–20 mA (2-wire) over a measuring range of 0–25 bar (0–362.5 psi), supply voltage 9–32 V DC. Pressure connection G 1/2 male; electrical connection Angular connector, Pg 9 (EN 175301-803-A). Pressure reference absolute. Accuracy ≤ ±1.0 % FS typical, ≤ ±2.0 % FS maximum. Wetted parts AISI 316L stainless steel; enclosure IP65. Spec key AKS 3000-2421-A1AB08-0. Approvals: ATEX Ex ec IIA T4 Gc, CE, UL Recognized. EAN 5702423133628.
Specifications
- Part number
- 060G1608
- HS code
- 9026.20
- Material
- AISI 316L stainless steel
- Pressure rating
- 0–25 bar (0–362.5 psi)
- Temperature range
- -40 to +85 °C (ambient); 0 to +80 °C (compensated)
- IP rating
- IP65
- Standard size
- G 1/2 male
- Thread standard
- G 1/2 male
Compatibility
AKS 3000 transmitter; absolute reference, 4–20 mA (2-wire). G 1/2 male process port with Angular connector, Pg 9 (EN 175301-803-A).
