Danfoss DIN 43650 Form A cable plug, IP65, for 018F/018Z/042N Type B coils (30-Pack)
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss 042N0154 cable plug (EN 175301-803 Form A) for clip-on solenoid coils of the 018F, 018Z and 042N "Type B" range. 2 + E contacts, 250 V AC/DC, IP65, conductor up to 1 mm². Black body, CSA approval. Ordered separately from the coil and valve body. Catalogue multi-pack of 30 pcs.
Technical Specifications
- Type
- EN 175301-803 Form A cable plug
- Fits coils
- 018F / 018Z / 042N Type B (clip-on)
- Contacts
- 2 + E
- Voltage
- up to 250 V AC/DC
- Operating current
- max 16 A
- Enclosure
- IP65
- Conductor size
- max 1 mm²
- Contact resistance
- max 15 mOhm
- Ambient
- -40 to +90 °C
- Body colour
- black
- LED/surge suppression
- none
- Compliance
- CSA, EU RoHS
- Packing
- multi-pack (30 pcs)
- Code number
- 042N0154
- Product group
- Solenoid coil accessories
- Type designation
- Cable plug
- Ambient temperature range
- -40 °C to 90 °C
- Approval
- CSA
- REACH candidate-list substances
- No
- Net weight
- 0.02 kg
- EAN
- 5702428314206
- Colour
- Black
- Conductor size, max.
- 1.0 mm²
- Contact resistance max.
- 15 mOhm
- Electrical connection form
- Form A
- Electrical connection standard
- EN 175301-803
- Enclosure rating IP
- IP65
- Operating current max.
- 16.00 A
- Supply voltage [V] AC
- 250 V
- Supply voltage [V] DC
- 250.00 V
- Tolerance
- ± 15%
- EU RoHS compliance
- Yes
Standards & Compliance
- Material
- Thermoplastic body (black)
- Temperature Range
- -40 to +90 °C
- IP Rating
- IP65
- HS Code
- 8536.69
Compatibility & Fitment
EN 175301-803 Form A cable plug for the clip-on "Type B" coil range (018F / 018Z / 042N). Wire to 2 + E (conductor max 1 mm²); IP65 with fitted gasket. CSA approval. Verify coil connection form before ordering.
