Danfoss BH230CS hum-free solenoid valve coil 230 V AC clip-on terminal box with rectifier IP67
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss BH230CS clip-on solenoid coil, 230 V AC, 50/60 Hz, Terminal box with integral rectifier (junction box), IP67. Encapsulated coil with integral rectifier for hum-free AC operation and a 13.5 mm clip-on actuator for the EV-series valve range. OEM P/N 018F7301. Valve body ordered separately.
Technical Specifications
- Type
- BH230CS clip-on solenoid coil
- Supply
- 230 V AC, 50/60 Hz
- Power
- 22 W / 24 VA
- Connection
- Terminal box with integral rectifier (junction box) — hum-free
- Enclosure
- IP67
- Ambient
- -40 to +50 °C
- Actuator size
- 13.5 mm, clip-on
- Duty
- continuous
- Design standard
- VDE 0580
- Packing
- multi-pack (12 pc)
- EAN
- 5702423182435
- Fits EV210B / EV212B / EV220B / EV222B / EV224B / EV227B / EV250B / EV251B-series solenoid valve bodies — verify valve series on the datasheet
- Voltage
- 230 V
Standards & Compliance
- Material
- Encapsulated coil with integral rectifier
- Temperature Range
- -40 to +50 °C
- IP Rating
- IP67
- HS Code
- 8505.90
Compatibility & Fitment
Clip-on coil — mounts on the EV-series valve actuator (13.5 mm) without tools. Terminal box with integral rectifier (junction box). Verify valve series, supply voltage and connection type before ordering. Valve body ordered separately.
