Shrink tube; for Smart Printer; Unshrunk diameter: 3.2 mm; white
Pricing
Request a quote
We reply within 24 hours
Product Description
WAGO 211-501 Manufacturer description: Shrink tube; for Smart Printer; Unshrunk diameter: 3.2 mm; white. Wago Heat-shrink sleeve for Wago SmartPrinter.
Technical Specifications
- Manufacturer part number (MPN)
- 211-501
- EAN / GTIN
- 4055143370226
- Sales unit
- pcs
- Suitable
- for wire cross-section 0.75 … 1 mm²
- Marking method
- Thermal transfer
- Delivery form
- Roll
- Delivery form configuration
- 20 with roll
- Printing device
- Smart Printer (Thermal Transfer Printer)
- Depth
- 0.185 mm
- Mounting type
- Sliding on conductor
- Shrink rate
- 2:1
- Smear resistance
- in conjunction with 258-5005 Ink Ribbon
- Color
- white
- Material
- Polyolefin
- UV resistance
- EN 60068-2-5:2010 Procedure B
- Adhesive information
- without adhesive
- Halogen-free
- Yes
- Weight
- 180.5 g
- Ambient temperature (storage)
- +10 … +25 °C
- Ambient temperature (operation)
- -55 … +125 °C
- Relative humidity
- 45 … 55 %
- PU (SPU)
- 1 pcs
- Packaging type
- box
- Country of origin
- DK
- Customs tariff number
- 39173200900
- UNSPSC
- 39,121,705
- eCl@ss 10.0
- 27-40-04-01
- eCl@ss 9.0
- 27-40-04-01
- ETIM 9.0
- EC001530
- ETIM 10.0
- EC001530
- ECCN
- NO US CLASSIFICATION
- RoHS Compliance Status
- Compliant,No Exemption
- MPN
- 211-501
- Colour
- White
- Self-adhesive
- Yes
- Diameter
- 3.2 mm
- Length
- 20000 mm
- Text
- Unprinted
- Magnetic
- No
- Transparent
- No
Standards & Compliance
- HS Code
- 3926.90
Cross References
- EAN 4055143370226
- SAP 1200476873
- Code 82557696
Product Documentation
