Telemecanique XX6V3A1NAM12 Ultrasonic Sensor, Sn 1 m, NPN, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XX6V3A1NAM12 OsiSense XX ultrasonic proximity sensor, Sn 1 m, NPN output, M12 connector.
Technical Specifications
- Manufacturer part number (MPN)
- XX6V3A1NAM12
- EAN / GTIN
- 3666916079799
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Diameter
- 30 mm
- Output type
- NPN
- Nominal sensing distance Sn
- 1 m
- Voltage type
- AC/DC
- Max. output current
- 100 mA
- Housing material
- Plastic
- Ambient temperature
- 0–70 °C
- Switching frequency
- 70 Hz
- Type of electric connection
- Connector M12
- Type of switching output
- NPN/NPN
- Type of switch function
- Normally open contact (NO)
- Blind zone
- 100 mm
- Setting procedure
- Teach-In
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- No-load current
- 60 mA
- Relative linearity deflection
- 0.9 %
- Relative repeat accuracy
- 0.9 %
- Synchronisation possible
- No
- Supply voltage
- 12–24 V
- Material active area of sensor
- Plastic
- Degree of protection (IP)
- IP67
- Width sensor
- 30 mm
- Diameter sensor
- 30 mm
- Height of sensor
- 77 mm
- Length of sensor
- 95.6 mm
- Adjustable distance
- 100–1000 mm
- Measuring range length
- 100–1000 mm
- Country of origin
- United States
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916079799
- SAP 1000001646
- Code 8467635
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XCKP limit switch, plastic body, thermoplastic roller lever plunger head, horizontal actuation, 1 NC + 1 NO, slow action, spring return, Pg 11 cable entry, IP66/IP67 XCKP2521G11
Telemecanique
Telemecanique OsiSense XS630B4MAU20 Inductive Proximity Sensor — M30 barrel, Sn 22 mm, 2-Wire AC/DC, NO
Telemecanique
Telemecanique OsiSense XS612B1PBL2 Inductive Proximity Sensor — M12 barrel, Sn 4 mm, PNP, NC, pre-wired cable
Telemecanique
Telemecanique XCKP2145G11 Limit Switch, Adjustable-Length Roller Lever, Plastic Body, PG11 cable entry
Telemecanique
Telemecanique OsiSense XS506B1NAL2 Inductive Proximity Sensor — Ø6.5 mm barrel, Sn 6.5 mm, NPN, NO, pre-wired cable
Telemecanique
Telemecanique OsiSense XS630B1NAL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, NPN, NO, pre-wired cable
Telemecanique
Telemecanique XMLP016BC11F Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, DIN connector
Telemecanique
Telemecanique XUSL2E30H046NWH Safety Light Curtain Type 2, 30 mm resolution, hand detection, 460 mm protected height
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XX6V3A1NAM12?
- XX6V3A1NAM12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XX6V3A1NAM12.
- What is the HS code for XX6V3A1NAM12?
- The customs tariff (HS) code for XX6V3A1NAM12 is 8536.50.
- Who manufactures XX6V3A1NAM12?
- XX6V3A1NAM12 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XX6V3A1NAM12?
- Yes — the XX6V3A1NAM12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XX6V3A1NAM12?
- The minimum order quantity is 1.
- Is XX6V3A1NAM12 available?
- Yes — XX6V3A1NAM12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
