Telemecanique OsiSense XS630B1NAL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, NPN, NO, pre-wired cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XS630B1NAL2 is an OsiSense XS inductive proximity sensor in an M30 nickel-plated brass threaded barrel, with a nominal sensing distance (Sn) of 15 mm. It provides a NPN (3-wire DC) output, switching NO (normally open), via pre-wired cable. IP67 protection, operating range -25 °C to +70 °C, with output-state LED indication. Conforms to IEC 60947-5-2.
Technical Specifications
- Manufacturer part number (MPN)
- XS630B1NAL2
- EAN / GTIN
- 3666916011904
- Product type
- OsiSense XS inductive proximity sensor
- Housing
- M30 cylindrical threaded barrel (Nickel-plated brass)
- Nominal sensing distance Sn
- 15 mm
- Output
- NPN (3-wire DC)
- Switching function
- NO (normally open)
- Connection
- pre-wired cable
- Degree of protection
- IP67
- Operating temperature
- -25 °C to +70 °C
- Conforms to
- IEC 60947-5-2
- HS code
- 8536.50
- Sales unit
- pcs
- Package quantity
- 44 pcs
Standards & Compliance
- Standard
- IEC 60947-5-2
- Material
- Nickel-plated brass
- Temperature Range
- -25 °C to +70 °C
- IP Rating
- IP67
- HS Code
- 8536.50
Cross References
- EAN 3666916011904
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XMLP016BC11F Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, DIN connector
Telemecanique
Telemecanique XUSL2E30H046NWH Safety Light Curtain Type 2, 30 mm resolution, hand detection, 460 mm protected height
Telemecanique
Telemecanique XCKP2102G11 Limit Switch, Metal Roller Plunger, 1 NO + 1 NC, PG11 entry
Telemecanique
Telemecanique XUB5BPAWL2 Photoelectric Sensor M18, Metal, PNP, 2 m cable
Telemecanique
Telemecanique XCKD2121G11 Limit Switch, Roller Lever Arm, Plastic Body, 1 NO + 1 NC, PG11 entry
Telemecanique
V Giveree M12 PNP NO 24VDC M12
XS212BLPAM12
Telemecanique
Telemecanique XCKP2110M12 Limit Switch, Metal Plunger, M12 connector
Telemecanique
Telemecanique OsiSense XS230BLPBL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, PNP, NC, pre-wired cable
Technical guides
- Inductive Proximity Sensor Cross-Reference — Telemecanique OsiSense XS, Carlo Gavazzi ICB, Omron E2E, Eaton E57, Turck, Pepperl+Fuchs by Housing, Sensing Distance and Output
- Emergency Stop Rope Pull Switches — Covering Conveyors to EN ISO 13850 with XY2C
- Inductive Proximity Sensors — Diameter, Sensing Distance, Flush Mounting, PNP/NPN and NO/NC Explained
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XS630B1NAL2?
- XS630B1NAL2 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XS630B1NAL2.
- What is the HS code for XS630B1NAL2?
- The customs tariff (HS) code for XS630B1NAL2 is 8536.50.
- Who manufactures XS630B1NAL2?
- XS630B1NAL2 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XS630B1NAL2?
- Yes — the XS630B1NAL2 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XS630B1NAL2?
- The minimum order quantity is 1.
- Is XS630B1NAL2 available?
- Yes — XS630B1NAL2 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
