Telemecanique ZBVB57 LED Module, Yellow, 24 V, PCB Mounting, for Harmony Pilot Lights
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique ZBVB57 LED lamp module, yellow, 24 V, PCB (print) mounting, for Harmony XB4/XB5 pilot lights and illuminated pushbuttons.
Technical Specifications
- Manufacturer part number (MPN)
- ZBVB57
- EAN / GTIN
- 3389110090420
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Voltage
- 24 V
- Range of product
- Harmony XB5; Harmony XB4
- Product or component type
- Light block
- Device short name
- ZBV
- Sale per indivisible quantity
- 5
- Connections - terminals
- Pins for printed circuit board
- Signalling type
- Steady
- Light source
- Protected LED
- Bulb base
- Integral LED
- Light block supply
- Direct
- Light source colour
- Orange
- [Us] rated supply voltage
- 24 V AC/DC at 50/60 Hz
- Product weight
- 0.004 kg
- Supply voltage limits
- 19.2…30 V DC; 21.6…26.4 V AC
- Current consumption
- 15 mA
- Service life
- 100000 h at rated voltage and 25 °C
- Surge withstand
- 1 kV conforming to IEC 61000-4-5
- Mounting of block
- Front mounting
- Electrical composition code
- M1; M2; M3; M4; M5; M6; M10; MF1; P1; P2; PF1
- Protective treatment
- TH
- Ambient air temperature for storage
- -40…70 °C
- Ambient air temperature for operation
- -40…70 °C
- IP degree of protection
- IP20 conforming to IEC 60529
- Standards
- CSA C22.2 No 14; IEC 60947-5-5; JIS C8201-5-1; IEC 60947-5-1; IEC 60947-1; IEC 60947-5-4; UL 508; JIS C8201-1
- Resistance to fast transients
- 2 kV conforming to IEC 61000-4-4
- Resistance to electromagnetic fields
- 10 V/m conforming to IEC 61000-4-3
- Resistance to electrostatic discharge
- 6 kV on contact (on metal parts) conforming to IEC 61000-4-2; 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2
- Electromagnetic emission
- Class B conforming to IEC 55011
- Supply voltage
- 24 V
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 5
- Country of origin
- FR
- Warranty (in months)
- 18
- Transformer integrated
- No
- With integrated voltage decreasing resistor
- No
- With integrated diode
- Yes
- Colour light source
- Orange
- Lamp type
- LED
- Type of fastening
- Front fastening
- With light source
- Yes
- Connection type auxiliary circuit
- PCB connection
- Rated voltage Ue at AC 50 Hz
- 24 V
- Rated voltage Ue at DC
- 24 V
- Voltage type for actuating
- AC/DC
Standards & Compliance
- HS Code
- 8531.80
Cross References
- EAN 3389110090420
- SAP 1000529534
- Code 8890824
Product Documentation
