Telemecanique XCSDMP5012 Magnetic Safety Switch, 2 NO + 1 NC, 2 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP5012 magnetic safety interlock switch for guard-door monitoring, 2 NO + 1 NC contacts, 2 m cable.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP5012
- EAN / GTIN
- 3666916059845
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Contact configuration
- 2 NO + 1 NC
- Number of protected contact energized outputs
- 3
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Coating housing
- Uncoated
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- No
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP66
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916059845
- SAP 1000072251
- Code 8789079
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XCKN2108P20 Limit Switch, Cat's Whisker (Spring Rod), NC+NO, Plastic Body, M20 cable entry
Telemecanique
Limit SWITCH,METAL 2 POLE Nc+no (XCRE18)
Telemecanique
Schneider Electric multifunction phase control relay RM35-T - range 194..528 V AC RM35TF30
Telemecanique
Telemecanique XZCC12FDM50B Field-Wireable Connector, M12, Female, Straight, 5-pin, Metal
Telemecanique
Telemecanique motor voltage and temperature control relay - RM35-T - 24..240 V AC/DC - 2 NO RM35TM50MW
Telemecanique
Telemecanique XCRZ04 Limit Switch Square Rod 300 mm
Telemecanique
Telemecanique XS130B3PAM12 Inductive Proximity Sensor Ø30 mm, Threaded, PNP NO, M12 connector
Telemecanique
Telemecanique ZBVB17 LED Module, White, 24 V, PCB Mounting, for Harmony Pilot Lights
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP5012?
- XCSDMP5012 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP5012.
- What is the HS code for XCSDMP5012?
- The customs tariff (HS) code for XCSDMP5012 is 8544.42.
- Who manufactures XCSDMP5012?
- XCSDMP5012 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP5012?
- Yes — the XCSDMP5012 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP5012?
- The minimum order quantity is 1.
- Is XCSDMP5012 available?
- Yes — XCSDMP5012 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
