Telemecanique ZBVB17 LED Module, White, 24 V, PCB Mounting, for Harmony Pilot Lights

Telemecanique ZBVB17 LED lamp module, white, 24 V, PCB (print) mounting, for Harmony XB4/XB5 pilot lights and illuminated pushbuttons.

Manufacturer part number (MPN)

ZBVB17

EAN / GTIN

3389110090369

Sales unit

pcs

Package quantity

5 pcs

Voltage

24 V

Range of product

Harmony XB4; Harmony XB5

Product or component type

Light block

Device short name

ZBV

Sale per indivisible quantity

5

Connections - terminals

Pins for printed circuit board

Signalling type

Steady

Light source

Protected LED

Bulb base

Integral LED

Light block supply

Direct

Light source colour

White

[Us] rated supply voltage

24 V AC/DC at 50/60 Hz

Product weight

0.004 kg

Supply voltage limits

19.2…30 V DC; 21.6…26.4 V AC

Current consumption

15 mA

Service life

100000 h at rated voltage and 25 °C

Surge withstand

1 kV conforming to IEC 61000-4-5

Mounting of block

Front mounting

Electrical composition code

M1; M2; M3; M4; M5; M6; M10; MF1; P1; P2; PF1

Protective treatment

TH

Ambient air temperature for storage

-40…70 °C

Ambient air temperature for operation

-40…70 °C

IP degree of protection

IP20 conforming to IEC 60529

Standards

CSA C22.2 No 14; IEC 60947-1; IEC 60947-5-5; UL 508; IEC 60947-5-4; JIS C8201-5-1; IEC 60947-5-1; JIS C8201-1

Resistance to fast transients

2 kV conforming to IEC 61000-4-4

Resistance to electromagnetic fields

10 V/m conforming to IEC 61000-4-3

Resistance to electrostatic discharge

6 kV on contact (on metal parts) conforming to IEC 61000-4-2; 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2

Electromagnetic emission

Class B conforming to IEC 55011

Supply voltage

24 V

Number of Units in Package 1

1

Number of Units in Package 2

5

Number of Units in Package 3

200

Country of origin

FR

Warranty (in months)

18

Transformer integrated

No

With integrated voltage decreasing resistor

No

With integrated diode

Yes

Colour light source

White

Lamp type

LED

Type of fastening

Front fastening

With light source

Yes

Connection type auxiliary circuit

PCB connection

Rated voltage Ue at AC 50 Hz

24 V

Rated voltage Ue at AC 60 Hz

24 V

Rated voltage Ue at DC

24 V

Voltage type for actuating

AC/DC

HS Code

8531.80
