Telemecanique XCKJ161 Limit Switch, Metal Body, 1 NO + 1 NC
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCKJ161 limit switch (position switch), metal body, 1 NO + 1 NC contacts.
Technical Specifications
- Manufacturer part number (MPN)
- XCKJ161
- EAN / GTIN
- 3666916094358
- HS code
- 8536.90
- Sales unit
- pcs
- Contact configuration
- 1 NO + 1 NC
- Switching function
- Quick-break switch
- Rated operation current Ie at AC-15, 230 V
- 3 A
- Rated operation current Ie at DC-13, 230 V
- 0.27 A
- Housing material
- Metal
- Suitable for safety functions
- No
- With status indication
- No
- Type of interface for safety communication
- None
- Type of electric connection
- Cable entry PG
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Degree of protection (IP)
- IP66/IP67
- Forced opening
- Yes
- Type of control element
- Plunger
- Type of interface
- None
- Output electronic
- No
- Rated operation current Ie at AC-15, 125 V
- 3 A
- Width sensor
- 40 mm
- Height of sensor
- 77 mm
- Length of sensor
- 44 mm
- Switching function latching
- No
- Ambient temperature during operating
- -25–70 °C
- Number of contacts as normally closed contact
- 1
- Number of contacts as normally open contact
- 1
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916094358
- SAP 1000035621
- Code 8513948
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XZCC20FDM30B Field-Wireable Connector, 1/2"-20 UNF, Female, Straight, 3-pin, Metal
Telemecanique
Telemecanique XCKJ167 Limit Switch, Metal Body, 1 NO + 1 NC
Telemecanique
Telemecanique XUX0ARCTT16T Photoelectric Emitter, XUX Multipurpose, Multi-Voltage AC/DC, screw terminals
Telemecanique
Telemecanique XCKJ10511 Limit Switch, Metal Body, 1 NO + 1 NC
Telemecanique
Telemecanique XZCP11V12L10 Sensor Cable, M12 female straight, 5-pin, PUR, 10 m
Telemecanique
Telemecanique OsiSense XS4P18KP340D Inductive Proximity Sensor — M18 barrel, Sn 8 mm, PNP or NPN, programmable, NO or NC, M12 connector (4-Pin)
Telemecanique
Telemecanique ZCKY91 Actuator Lever for ZCK Limit Switches
Telemecanique
Telemecanique XMLA004A2C11 Pressure Switch, 0.4–4 bar, DIN connector
Technical guides
- Limit Switch and Position Switch Finder — by Actuator (Roller Plunger, Roller Lever, Rod Lever, Plunger, Spring Rod) and Contacts — Telemecanique XCK, Siemens 3SE5, Eaton LS, R. Stahl Ex
- Emergency Stop Rope Pull Switches — Covering Conveyors to EN ISO 13850 with XY2C
- Inductive Proximity Sensors — Diameter, Sensing Distance, Flush Mounting, PNP/NPN and NO/NC Explained
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCKJ161?
- XCKJ161 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCKJ161.
- What is the HS code for XCKJ161?
- The customs tariff (HS) code for XCKJ161 is 8536.90.
- Who manufactures XCKJ161?
- XCKJ161 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XCKJ161?
- Yes — the XCKJ161 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCKJ161?
- The minimum order quantity is 1.
- Is XCKJ161 available?
- Yes — XCKJ161 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
