Telemecanique XZCC43FCP40B Field-Wireable Connector, Female, Angled, Metal
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XZCC43FCP40B field-wireable (user-attachable) connector, female angled, metal body, screw-clamp wiring, for sensor and actuator cabling.
Technical Specifications
- Manufacturer part number (MPN)
- XZCC43FCP40B
- EAN / GTIN
- 3666916069813
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 50 pcs
- Contact type
- Pin
- Width
- 30 mm
- Height
- 30 mm
- Depth
- 36 mm
- Number of poles
- 4
- Rated current In
- 16 A
- Ambient temperature
- -40–125 °C
- Rated voltage
- 250 V
- Connectable conductor cross section solid-core
- 0–1.5 mm²
- Connectable conductor cross section multi-wired
- 0–1.5 mm²
- Type of electric connection
- Screw connection
- Housing material
- Plastic
- Coating housing
- Uncoated
- Type of locking
- None
- Polarization
- None
- Mounting method
- Screwed
- With interlocking device
- Yes
- With protective conductor
- No
- Operating temperature
- -40–125 °C
- Degree of protection (IP), mounted
- IP65
- EMC-version
- No
- With sealing
- No
- Position cable feed
- Vertical
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916069813
- SAP 1000014376
- Code 8484545
Product Documentation
