SS316 Equal Tee BSP Female 2"
Generic · Pipes, Fittings & Flanges · Equal Tees
Generic 316-TEEF-2BSP, catalog identifier for the specific configuration. SS316 cast equal tee with female BSP threads on all three ends. 2" size for main header branching. Supplied for general industrial and marine service under the applicable OEM specification. Manufacturer: Generic. Manufacturer part number: 316-TEEF-2BSP. Available on quote-to-invoice terms via cBallast. Lead time and freight are quoted per RFQ against destination Incoterm.
Specifications
- Part number
- 316-TEEF-2BSP
- HS code
- 7307.19
- Material
- AISI 316 Stainless Steel
- Pressure rating
- 150 lbs (PN10)
- Temperature range
- -20°C to +200°C
- Standard
- ISO 4144
- Standard size
- 2" BSP
- Thread standard
- BSP (ISO 228-1)
Compatibility
Interchanges with Swagelok 316 SS pipe fitting female tee series (-T-RT), but Swagelok does not list a 2 in. BSPT pipe tee in 316; item is available from other OEMs only.
Standards
- ISO 9001
- NACE MR0175/ISO
- ASME B31.3
- ISO 228-1
- ISO 4144
Approvals
