SS316 Reducing Nipple BSP 1/2" x 3/8"
Generic · Pipes, Fittings & Flanges · Reducing Nipples
SS316 reducing nipple with male BSP threads. Reduces from 1/2" to 3/8".
Specifications
- Part number
- 316-REDNIP-1/2x3/8BSP
- HS code
- 7307.19
- Material
- AISI 316 Stainless Steel
- Pressure rating
- 150 lbs (PN10)
- Temperature range
- -20°C to +200°C
- Standard
- ISO 4144
- Standard size
- 1/2" x 3/8" BSP
- Thread standard
- BSP (ISO 228-1)
Compatibility
BSPT 1/2 x 3/8 reducing hex nipple. Swagelok lists the dimensionally equivalent NPT part SS-8-HRN-6 (316 SS); Swagelok does not produce a dedicated BSPT reducing hex nipple, so use SS-8-HRN-6 for reference (material/dimensions) or source BSPT from an alternate supplier.
Standards
- ISO 9001
- NACE MR0175/ISO
- ASME B31.3
- ISO 228-1
- ISO 4144
- ASME B31.3.
- ISO 15156
Approvals
