SS316 Reducing Nipple BSP 1" x 3/4"
Generic · Pipes, Fittings & Flanges · Reducing Nipples
SS316 reducing nipple with male BSP threads. Reduces from 1" to 3/4".
Specifications
- Part number
- 316-REDNIP-1x3/4BSP
- HS code
- 7307.19
- Material
- AISI 316 Stainless Steel
- Pressure rating
- 150 lbs (PN10)
- Temperature range
- -20°C to +200°C
- Standard
- ISO 4144
- Standard size
- 1" x 3/4" BSP
- Thread standard
- BSP (ISO 228-1)
Compatibility
BSPT 1 x 3/4 reducing hex nipple. Swagelok lists the dimensionally equivalent NPT part SS-16-HRN-12 (316 SS); Swagelok does not produce a dedicated BSPT reducing hex nipple, so use SS-16-HRN-12 for reference (material/dimensions) or source BSPT from an alternate supplier.
Standards
- ISO 9001
- NACE MR0175/ISO
- ASME B31.3
- ISO 228-1
- ISO 4144
- ASME B31.3.
- ISO 15156
Approvals
