SS316 Reducing Nipple BSP 3/4" x 1/2"

Name: SS316 Reducing Nipple BSP 3/4" x 1/2"
Brand: Generic
SKU: CB-316-REDNIP-3/4X1/2
Price: 20.99 USD
Availability: InStock

Generic · Pipes, Fittings & Flanges · Reducing Nipples

SS316 reducing nipple with male BSP threads. Reduces from 3/4" to 1/2".

Specifications

Part number: 316-REDNIP-3/4x1/2BSP
HS code: 7307.19
Material: AISI 316 Stainless Steel
Pressure rating: 150 lbs (PN10)
Temperature range: -20°C to +200°C
Standard: ISO 4144
Standard size: 3/4" x 1/2" BSP
Thread standard: BSP (ISO 228-1)

Compatibility

BSPT 3/4 x 1/2 reducing hex nipple. Swagelok lists the dimensionally equivalent NPT part SS-12-HRN-8 (316 SS); Swagelok does not produce a dedicated BSPT reducing hex nipple, so use SS-12-HRN-8 for reference (material/dimensions) or source BSPT from an alternate supplier.

Standards

ISO 9001
NACE MR0175/ISO
ASME B31.3
ISO 228-1
ISO 4144
ASME B31.3.
ISO 15156

Approvals

PED
NACE MR0175
