Schneider ACTI9 IHP Timer - 230V, 18

Schneider Acti9 IHP Timer. Time and function relays (Electrical Engineering / Components for panels and boxes). Principal data: voltage 230 V, module size 18. Supplied under manufacturer part number CCT15838, EAN 3606480769238, HS code 9107.00, country of origin Germany.

Product type

Time and function relays Product group: Components for panels and boxes Voltage: 230 V Module size: 18 REACH SVHC substance above 0.1%: Lead, Diarylmethane, Diboron-trioxide, Lead-monoxide, Octrizole Carbon footprint (EPD): 1.6062 kg CO2e per pcs Country of origin: Germany Customs tariff code (EU CN): 91070000 HS code: 9107.00 Manufacturer part number: CCT15838 range of product: Acti9 Product name: Acti9 IHP Device short name: IHP+ Product or component type: Programmable digital time switch Device application: Building battery type: Lithium Number of channels: 1 Available equipment: Memory key User language: Italian; Portuguese; French; Spanish; Dutch; English Colour tint: White (RAL 9003) Load type: incandescent lamp: <= 2000 W; halogen lamp: <= 2000 W; parallel-corrected fluorescent tube with conventional ballast: <= 1300 W (140 µF); fluocompact lamp with electronic ballast: <= 300 W; dual corrected fluorescent tube with conventional ballast: <= 2000 W; non-corrected fluorescent tube with conventional ballast: <= 2000 W; dual mounted fluorescent tube with conventional ballast: <= 2000 W; 2...8 W LED lamp: <= 180 W; < 2 W LED lamp: <= 55 W Maximum switching current: 16 A - 250 V AC pf = 1; 4 A - 250 V AC pf = 0.6 [Ue] rated operational voltage: 230 V AC - 15...10 % at 50/60 Hz Number of inputs: 1 input(s) impulse and maintained Accuracy: +/- 0.25 s/day 25 °C Cycle duration: 24 hours + 7 days Maximum number of switchings: 84 minimum interval duration: 1 s Function available: Operating hours counter; Automatic winter/summer time changeover; External input for override; Pulse programming Display type: LCD Battery life: 10 year(s) Backup time: 10 years time and program saving Type of setting: Absence for holidays function; PIN code; Random function Connections - terminals: 2 x 0.5…2.5 mm² screwless terminals Mounting support: DIN rail 9 mm pitches: 2 Width: 18 mm Height: 90 mm Depth: 66 mm Product weight: 0.09 kg Function: Pulse programming, random function, external input for override Absence for holidays: Yes Time changeover: Automatic Updated by: None Compatibility code: IHP Ambient air temperature for operation: -25…55 °C IP degree of protection: IP20 Number of Units in Package 1: 1 Number of Units in Package 2: 86 Warranty (in months): 18 EAN: 3606480769238

HS Code

9107.00

• EAN 3606480769238
• MPN CCT15838
