Schneider Electric plug-in electromechanical relay - 12.5 mm - 24 V DC - 1 CO ABR7S33

Schneider Electric ABR7S33 Relay 12mm 24VDC, 1C/O, Ith=10A.

Manufacturer part number (MPN)

ABR7S33 EAN / GTIN: 3389110720747 HS code: 8536.90 Sales unit: pcs Package quantity: 4 pcs Voltage: 24 V DC Range of product: Advantys Telefast ABE7 Product or component type: Plug-in electromechanical relay Control circuit type: DC minimum ordered quantity: Set of 4 Width pitch dimension: 12 mm Product compatibility: ABE7P08T330E; ABE7R16T332; ABE7P16T334; ABE7P16T318E; ABE7P16T318; ABE7P16T332; ABE7P16T330; ABE7R16T330; ABE7P16T330E; ABE7P08T330 [Uc] control circuit voltage: 24 V [Ith] conventional free air thermal current: 10 A Contacts type and composition: 1 C/O Threshold tripping voltage: 16.8 V at 40 °C Drop-out voltage: 3.6 V at 20 °C Drop-out current: 3.5 mA at 20 °C Maximum power dissipation per pole: 0.6 W Associated fuse rating: 1 A, fast blow Maximum switching voltage: 130 V DC conforming to IEC 60947-5-1; 264 V AC 50/60 Hz conforming to IEC 60947-5-1 Electrical durability: 500000 cycles, maximum switching current: 1400 mA at 24 V DC-13 10 ms; 500000 cycles, maximum switching current: 1700 mA at 230 V AC-15; 500000 cycles, maximum switching current: 3000 mA at 230 V AC-12; 500000 cycles, maximum switching current: 3000 mA at 24 V DC-12 minimum switching current: 100 mA at >= 5 V electrical reliability: 1e-008 Operating rate in Hz: 5 Hz no load; 0.5 Hz at Ie Mechanical durability: 20000000 cycles [Uimp] rated impulse withstand voltage: 2.5 kV conforming to IEC 60947-1 Product weight: 0.017 kg Max immunity to microbreaks: 5 ms Dielectric strength: 2000 V conforming to IEC 60947-1 Country of origin: LV Warranty (in months): 18

HS Code

8536.90

• EAN 3389110720747
• SAP 1000070632
• Code 8758540
