Schneider Electric empty flush mounted box - XAP-E - insulated material - without opening - IP 65 XAPE901
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric XAPE901 Box For Front plate XAPE301.
Technical Specifications
- Manufacturer part number (MPN)
- XAPE901
- EAN / GTIN
- 3389110628104
- Sales unit
- pcs
- Package quantity
- 36 pcs
- Range of product
- Harmony XAP
- Product or component type
- Protective rear cover
- Device short name
- XAPE
- Product destination
- For front plate XAPE301
- Material
- Insulated material
- Cable entry
- Knock-out cable entries
- Product mounting
- Flush mounting
- IP degree of protection
- IP65 conforming to IEC 60529; IP65 conforming to NF C 20-010
- Resistance to chemical agents
- Good resistant to acetone; Good resistant to alcohols; Good resistant to chloride and fluoride solvents; Good resistant to diluted mineral acids; Good resistant to oils and petrol; Good resistant to organic acids; Good resistant to salts
- Product weight
- 0.04 kg
- Protective treatment
- TC; TH
- Ambient air temperature for storage
- -40…70 °C
- Ambient air temperature for operation
- -25…70 °C
- Electrical shock protection class
- Class I conforming to IEC 60536; Class I conforming to NF C 20-030
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 36
- Country of origin
- FR
- Warranty (in months)
- 18
- Width
- 59 mm
- Height
- 52 mm
- Depth
- 80 mm
- Colour housing cover
- Black
- Construction type housing
- Built-in housing
- Degree of protection (IP)
- IP65/IP67
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3389110628104
- SAP 1000026185
- Code 8237755
