Contact element 1 NO/NC

Schneider Electric 9001KA1 Contact Element 1 no/nc.

Manufacturer part number (MPN)

9001KA1

EAN / GTIN

3389110917840

Sales unit

pcs

Package quantity

100 pcs

Contact configuration

1 NO / NC

Range of product

Harmony 9001K; Harmony 9001SK

Product or component type

Contact block

Device short name

9001K

Contacts type and composition

1 C/O

Product weight

0.027 kg

Contact operation

Positive opening

Positive opening

Without

Connections - terminals

Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² conforming to IEC 60947-1

Tightening torque

0.8 N.m conforming to IEC 60947-1

Shape of screw head

Cross slotted

Contacts material

Silver alloy contacts

Short-circuit protection

10 A cartridge fuse conforming to IEC 60947-5-1

[Ith] conventional free air thermal current

10 A

[Ui] rated insulation voltage

250 V (pollution degree 3) conforming to IEC 60947-1

[Uimp] rated impulse withstand voltage

2.5 kV conforming to IEC 60947-1

[Ie] rated operational current

3 A at 240 V, AC-15, A600-Q600 conforming to NEMA; 0.55 A at 125 V, DC-13, A600-Q600 conforming to NEMA

[Icm] rated short-circuit making capacity

12 kA at 600 V AC-15, 7200 VA; 15 kA at 480 V AC-15, 7200 VA; 30 kA at 240 V AC-15, 7200 VA; 60 kA at 120 V AC-15, 7200 VA; 0.1 kA at 600 V DC-13, 7200 VA; 0.27 kA at 250 V DC-13, 7200 VA; 0.55 kA at 125 V DC-13

Rated breaking capacity

3 kA at 240 V AC-15, 720 VA; 6 kA at 120 V AC-15, 720 VA; 1.2 kA at 600 V AC-15, 720 VA; 1.5 kA at 480 V AC-15, 720 VA; 0.1 kA at 600 V DC-13; 0.27 kA at 250 V DC-13; 0.55 kA at 125 V DC-13

Supply voltage

0...600 V

Protective treatment

TC

Ambient air temperature for storage

-40…70 °C

Ambient air temperature for operation

-25…70 °C

Electrical shock protection class

Class II conforming to IEC 61140

Standards

IEC 60947-5-1; JIS C 4520; UL 508; IEC 60947-1; JIS C 852; CSA C22.2 No 14; IEC 60947-5-4; UL 60947-5-1

Product certifications

NEMA; UL 508

Vibration resistance

7 gn (f= 2…500 Hz) conforming to IEC 60068-2-6

Shock resistance

50 gn conforming to IEC 60068-2-27

Number of Units in Package 1

1

Number of Units in Package 2

100

Country of origin

FR

Warranty (in months)

18

HS Code

8536.50
