Schneider Electric 130mm Rotating Mirror Red 24VAC/DC IP67 XVR13B04L
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric XVR13B04L Rotary light 130mm IP66 24V red LED.
Technical Specifications
- Manufacturer part number (MPN)
- XVR13B04L
- EAN / GTIN
- 3389119045285
- Sales unit
- pcs
- Package quantity
- 6 pcs
- Voltage
- 24 V
- IP rating
- IP66
- Range of product
- Harmony XVR
- Product or component type
- Prewired rotating mirror beacon
- Sound signalling
- Without
- Device short name
- XVR
- Mounting diameter
- 130 mm
- IP degree of protection
- IP66 conforming to IEC 60529; IP67 conforming to IEC 60529
- [Us] rated supply voltage
- 24 V AC/DC
- Light source
- High luminosity LED, red
- Material
- ABS (acrylonitrile butadiene-styrene): body part; PC: globe
- CAD overall width
- 130 mm
- CAD overall depth
- 130 mm
- Product weight
- 0.82 kg
- Marking
- CE
- Product mounting
- By 3 M6 screws
- [Uimp] rated impulse withstand voltage
- 0.8 kV
- Current consumption
- 125 mA
- Flashing frequency
- 2.7 Hz
- Clamping connection capacity
- 1.25 mm²
- AWG gauge
- 18 AWG
- Cable length
- 400 mm
- Standards
- IEC 61000-6-2; IEC 61000-6-4
- Protective treatment
- TC
- Ambient air temperature for storage
- -35…70 °C
- Ambient air temperature for operation
- -30…50 °C
- Electrical shock protection class
- Class II conforming to IEC 61140
- Country of origin
- ID
- Warranty (in months)
- 18
- Nominal voltage
- 24 V
- Type of current
- AC/DC
- Electricity consumption
- 0.125 A
- Power
- 3 W
- Degree of protection (IP)
- IP67
- Colour of lamp hood
- Red
- Lamp type
- LED
- Optics
- Mirror
Standards & Compliance
- HS Code
- 8531.80
Cross References
- EAN 3389119045285
- SAP 1000707740
- Code 8665963
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric Modular 1-Phase voltage control relay, 8 A, 2 CO, 15…500 V AC, 380…415 V AC RM22UA33MT
Schneider Electric
Schneider Electric PratiKa socket - fast - angled - 16A - 2P + E - 380...415 V AC - panel PKY16F433
Schneider Electric
Flat rail-LGY BS-horizontal- 80X10MM
LVS04548
Schneider Electric
Schneider Electric Schneider Electric EASY UPS BVS 500VA, IEC outlet BVS500I
Schneider Electric
Selector switch with LIGHT 3POS.RET.H/V RED
ZB5AK1543
Schneider Electric
Euro utt 2P 10A screw 1 mod hv
NU303118
Schneider Electric
Contact element 1 NO/NC
9001KA1
Schneider Electric
Schneider Electric transfer switch, TransferPacT automatic, 32A, 400V, 4P, rotary, frame 100A TA10D4S0324TPE
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XVR13B04L?
- XVR13B04L can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is XVR13B04L.
- What is the HS code for XVR13B04L?
- The customs tariff (HS) code for XVR13B04L is 8531.80.
- Who manufactures XVR13B04L?
- XVR13B04L is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for XVR13B04L?
- Yes — the XVR13B04L datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XVR13B04L?
- The minimum order quantity is 1.
- Is XVR13B04L available?
- Yes — XVR13B04L is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
