Schneider Electric PanelSeT NSYTSA IP65 Cable Entry Plate 29 Entries 3-6.5 mm

Schneider Electric NSYTSA2429SE is a quick-fit polyamide cable entry plate for PanelSeT enclosures, providing 29 entries sized for cables 3-6.5 mm without additional glands. The plate mounts to the enclosure body or gland plate cut-out (146 x 14 mm) and delivers IP65 sealing after cable insertion. Applications include compact control enclosures and industrial boxes where fast, tool-free cable entry is required.

Manufacturer part number (MPN)

NSYTSA2429SE

EAN / GTIN

3606480168208

HS code

8544.42

Sales unit

pcs

Range

PanelSeT

Product or component type

Quick entrance plate

Accessory / separate part category

Cable management accessory

Device application

Multi-purpose

Range compatibility

PanelSeT S3D compact enclosure; PanelSeT CRN compact enclosure; PanelSeT S3CM control enclosure; PanelSeT SBM industrial box; PanelSeT PLA suitable enclosure; PanelSeT PHD suitable enclosure; PanelSeT PLM compact enclosure; PanelSeT PLS insulating modular box; PanelSeT S3HD compact enclosure

Device composition

1 fixing elements; 1 plate

Quantity per set

Set of 1

Mounting support

Body of enclosure; Cable gland plate

Material

Polyamide

Fixing mode

By fixing element

Total cable entry number

29

Cable entry number

29 x 3…6.5 mm

Height

Real: 14 mm

Width

Real: 146 mm; Cut-out: 112 mm; Fixing center: 130 mm

Depth

Real : 58 mm; Cut-out : 36 mm; Fixing centre : 32 mm

Product weight

0.16 kg

IP degree of protection

IP65

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

3.500 cm

Package 1 Width

8.000 cm

Package 1 Length

17.000 cm

Package 1 Weight

148.000 g

Unit Type of Package 2

P12

Number of Units in Package 2

200

Package 2 Height

37.000 cm

Package 2 Width

80.000 cm

Package 2 Length

120.000 cm

Package 2 Weight

49.000 kg

Country of origin

FR

Warranty (in months)

18

HS Code

8544.42

• EAN 3606480168208
• SAP 1000402085
• Code 8475157
