Jf.relay RH10M 380/415VAC 300MA
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 56145 RH10M 440/525V AC 50/60HZ SEUIL 1A INSTA.
Technical Specifications
- Manufacturer part number (MPN)
- 56145
- EAN / GTIN
- 3303430561453
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Voltage
- 380/415 V AC
- External power supply required
- Yes
- Rated switch current
- 8 A
- Voltage type (operating voltage)
- AC
- Type of electric connection
- Screw connection
- Voltage type for actuating
- AC
- With detachable clamps
- No
- Function
- For AC-current system
- Response value amperage 2
- 0–30 mA
- Min. adjustable delay-on energization time
- 0 s
- Max. permitted delay-on energization time
- 0.04 s
- Indication of difference current
- No
- Error registration possible
- No
- Number of contacts as normally open contact
- 1
- Number of contacts as change-over contact
- 1
- Width
- 54 mm
- Height
- 97 mm
- Depth
- 74 mm
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3303430561453
- SAP 1000284748
- Code 868790
Product Documentation
