Schneider Electric plug-in electromechanical relay - 10 mm - 24 V DC - 1 NO ABR7S21

Schneider Electric ABR7S21 Relay 10mm 24VDC, 1N/O, Ith=5A.

Manufacturer part number (MPN)

ABR7S21 EAN / GTIN: 3389110644739 HS code: 8536.90 Sales unit: pcs Package quantity: 4 pcs Voltage: 24 V DC Range of product: Advantys Telefast ABE7 Product or component type: Plug-in electromechanical relay Control circuit type: DC minimum ordered quantity: Set of 4 Width pitch dimension: 10 mm Product compatibility: ABE7P16T212; ABE7P16T214; ABE7P16T210; ABE7P16T230E; ABE7R16T210; ABE7R16T212; ABE7P16T215; ABE7P16T230 [Uc] control circuit voltage: 24 V [Ith] conventional free air thermal current: 5 A Contacts type and composition: 1 NO Threshold tripping voltage: 19.7 V at 40 °C Drop-out voltage: 2.4 V at 20 °C Drop-out current: 1 mA at 20 °C Maximum power dissipation per pole: 0.36 W Associated fuse rating: 1 A, fast blow Maximum switching voltage: 130 V DC conforming to IEC 60947-5-1; 250 V AC 50/60 Hz conforming to IEC 60947-5-1 Electrical durability: 500000 cycles, maximum switching current: 1500 mA at 230 V AC-12; 500000 cycles, maximum switching current: 1500 mA at 24 V DC-12; 500000 cycles, maximum switching current: 600 mA at 24 V DC-13 10 ms; 500000 cycles, maximum switching current: 900 mA at 230 V AC-15 minimum switching current: 10 mA at >= 5 V electrical reliability: 1e-008 Operating rate in Hz: 10 Hz no load; 0.5 Hz at Ie Mechanical durability: 20000000 cycles [Uimp] rated impulse withstand voltage: 2.5 kV conforming to IEC 60947-1 Width: 10 mm Product weight: 0.008 kg Max immunity to microbreaks: 5 ms Dielectric strength: 2000 V conforming to IEC 60947-1 Country of origin: LV Warranty (in months): 18

HS Code

8536.90

• EAN 3389110644739
• SAP 1000044257
• Code 8782085
