RAIL 800-1000A 2M 6 Outlet

Schneider Electric KSA1000ED4206 Rail 800-1000A 2M 6 outlet.

Manufacturer part number (MPN)

KSA1000ED4206

EAN / GTIN

3606480003806

Sales unit

pcs

Range

Canalis

Device short name

KSA

Offer type

Advanced

Product or component type

Busbar trunking

Busbar description

Horizontal distribution length

Product compatibility

Canalis KSA busbar trunking 500…1000 A

Conductors material

Aluminium

Busbar trunking polarity

3L + N + PE

Number of tap-off outlets

6

[Ie] rated operational current

1000 A at 35 °C

IP degree of protection

IP55 conforming to IEC 60529

mounting mode

By screws

Dimension type

Fix

Length

2 m

Colour

White (RAL 9001)

Number of poles

4

Neutral position

Up

Mounting position

Horizontal

[Ue] rated operational voltage

230...690 V

Network frequency

50/60 Hz

[Uimp] rated impulse withstand voltage

8 kV

[Ui] rated insulation voltage

690 V

[Icw] rated short-time withstand current

37.4 kA

[Ipk] rated peak withstand current

78.7 kA

Electrical connection

Lubricated sliding contact

Width

113 mm

Height

146 mm

Product weight

38.05 kg

Tap-off unit interval

500 mm

Radiated magnetic field

1.27 µT

Thermal stress limit

1758000 kA².s

THDI

0…15 % 1000 A; 15…33 % 800 A; 33…100 % 630 A

Maximum voltage drop

<0.005 V with power factor = 1 at 50 Hz with 1A for 100 m long; <0.007 V with power factor = 0.9 at 50 Hz with 1A for 100 m long; <0.007 V with power factor = 0.8 at 50 Hz with 1A for 100 m long; <0.008 V with power factor = 0.7 at 50 Hz with 1A for 100 m long

Standards

IEC 61439-1; IEC 61439-6

IK degree of protection

IK08 conforming to IEC 62262

Ambient air temperature for operation

35 °C (without derating); 55 °C (with derating factor)

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

16.500 cm

Package 1 Width

13.000 cm

Package 1 Length

217.000 cm

Package 1 Weight

36.000 kg

Unit Type of Package 2

PAL

Number of Units in Package 2

12

Package 2 Height

65.000 cm

Package 2 Width

64.000 cm

Package 2 Length

220.000 cm

Package 2 Weight

444.500 kg

Country of origin

FR

Warranty (in months)

18

Model

Single

Flexible

No

RAL-number

9001

Number of conductors (without earthing)

4

Degree of protection (IP)

IP55

Rated voltage AC 50 Hz

690 V

Number of tap-off units

6

Rated current AC 50 Hz

1000 A

HS Code

8536.90
