Graco XP50 High Flow Skid, 3:1 Mix Ratio, 240V, Viscon HF Heaters, Junction Box, No Hose Heat Control

Graco 578302 XP50 High Flow Skid, 3:1 Mix Ratio, 240V, Viscon HF Heaters, Junction Box, No Hose Heat Control, part number 578302. XP50s-hf plural-component proportioner, 3:1 mix ratio, 5000 psi (345 bar) maximum working pressure, 4 GPM maximum flow. Compatible material: Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents. All values read from the Graco product page (578302 on graco.com).

Brand

Graco Series: XP50s-hf Product type: Plural Component Part number: 578302 Type: Plural Component Sprayer Component type: Plural-Component Configuration: Skid Mount with 25 gal Heated & Agitated Hoppers Applicator type: Automatic Airless, Manual Airless material application: Coatings, Paints, Primers Power source: Air Measuring type: Fixed Mechanical Positive Displacement Flush type: Solvent Compatible material: Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents Mix ratio: 3:1 Maximum working pressure: 5000 psi (345 bar) Maximum spray pressure: 5000 psi (345 bar) Maximum flow rate: 4 GPM (15.1 L/min) (15480 cc/min) Maximum cycle rate: 40 CPM Maximum fluid temperature: 160 °F (71 °C) Maximum fluid viscosity: 20000 cP minimum fluid viscosity: 200 cP Maximum hose length: 300 ft (91.4 m) Fluid inlet size: 1-1/4 in NPT Fluid outlet size: 1/2 in NPT Air inlet size: 1 in NPSM Sound power level: 96 dB(A) Sound pressure level: 86.8 dB(A) Wetted material: Electroless Nickel Plating, Plated Carbon Steel, Stainless Steel, Carbide, Acetal, UHMWPE, Nylon, PTFE, Solvent Resistant Plastics, Aluminum, Nylon Weight: 1350 lb (612 kg) Voltage: 240 V

Pressure Rating

5000 psi (345 bar) max working

Temperature Range

up to 160 °F (71 °C) fluid

HS Code

8424.20
