Graco T1 Package: Includes 2 Pumps (Stainless Steel) and 2 Supply Hoses

Graco 247956 T1 Package: Includes 2 Pumps (Stainless Steel) and 2 Supply Hoses, part number 247956. Graco T1 pneumatic (air-operated) piston transfer/supply pump. 2:1 pump ratio. 360 psi maximum working pressure. 2.5 gpm maximum flow rate. 1/2 in fluid outlet. Wetted material Stainless Steel. For industrial applications. All values read from the Graco product page (247956 on graco.com).

Brand

Graco

Line

T1

Part number

247956

Air Inlet Size (in)

1/4

Air Inlet Thread Gender

Female

Air Inlet Thread Type

NPT

Application

Industrial

Compatible Material

Polyurethane Materials

Cycles Per Gallon

40

Fluid Outlet Size (in)

1/2

Fluid Outlet Thread Gender

Female

Fluid Outlet Thread Type

NPT

Material

Stainless Steel

Maximum Air Inlet Pressure (MPa)

1.2

Maximum Air Inlet Pressure (psi)

180

Maximum Continuous Cycle Rate (CPM)

100

Maximum Flow Rate (GPM)

2.5

Maximum Operating Temperature (°F)

180

Maximum Working Pressure (MPa)

2.5

Maximum Working Pressure (psi)

360

Model

T1

Package Options

Supply Hose

Pump Ratio

2:1

Seal Material

PTFE

Sound Power Level (dB(A))

96.8

Sound Pressure Level (dB(A))

88.7

Type

Pneumatic Piston Pump

Weight (lb)

18.5

Wetted Material

Stainless Steel

Air Inlet Size (mm)

6.35

Fluid Outlet Size (mm)

12.7

Maximum Air Inlet Pressure (bar)

12.5

Maximum Air Inlet Pressure (kPa)

1250

Maximum Flow Rate (L/min)

9.5

Maximum Operating Temperature (°C)

82

Maximum Working Pressure (bar)

25

Maximum Working Pressure (kPa)

2500

Weight (kg)

8.4

Material

Stainless Steel

Pressure Rating

360 psi max

HS Code

8413.50
