Graco Round Fusion Air-Purge Gun with 00 Mix Chamber and 0.029 in (0.74 mm) Orifice Size

Graco 246100 Round Fusion Air-Purge Gun with 00 Mix Chamber and 0.029 in (0.74 mm) Orifice Size, part number 246100. Fusion AP Round plural-component impingement-mix spray gun, 0.029 in (0.74 mm) fluid orifice, Round spray pattern. Maximum fluid pressure 3500 psi (241 bar). Maximum fluid temperature 200 °F. Compatible material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam. All values read from the Graco product page (246100 on graco.com).

Brand

Graco Model: Fusion AP Series: Round Part number: 246100 Type: Spray Gun Gun type: Air Purge Gun Component type: Plural-Component Applicator type: Manual Trigger type: Two-Finger Compatible material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam Spray pattern: Round Pattern size: 8 in @ 24 in from target Fluid orifice size: 0.029 in (0.74 mm) Mix chamber: 00 (.029) Impingement port size: 0.029 in (0.70 mm) Maximum fluid pressure: 3500 psi (241 bar) Maximum fluid working pressure: 3500 psi (245 bar) Maximum air inlet pressure: 130 psi (9 bar) minimum air inlet pressure: 80 psi (5.5 bar) Maximum fluid temperature: 200 °F (93 °C) Maximum flow rate @ pressure: 50 lb/min Air inlet size: 1/4 in NPT Component A inlet size: 1/2-20 in UNF Component B inlet size: 9/16-18 in UNF Sound pressure level: 81.1 dB(A) Sound power level: 91 dB(A) Gun weight: 2.5 lb (1.1 kg) Overall length: 7.5 in (191 mm) Overall height: 8.1 in (206 mm) Overall width: 3.3 in (84 mm) For use with: Non-Flammable Foam and Polyurea

Pressure Rating

3500 psi (241 bar) max fluid

Temperature Range

up to 200 °F (93 °C)

HS Code

8424.20
