Graco Fusion Automatic Solvent-Purge Gun
Pricing
Request a quote
We reply within 24 hours
Product Description
Graco 248647 Fusion Automatic Solvent-Purge Gun, part number 248647. Fusion MP Specialty plural-component impingement-mix spray gun. Maximum fluid pressure 3500 psi (241 bar). Maximum fluid temperature 200 °F. Compatible material: Non-Flammable Foam, Polyurea. All values read from the Graco product page (248647 on graco.com).
Technical Specifications
- Brand
- Graco Model: Fusion MP Series: Specialty Part number: 248647 Type: Spray Gun Gun type: Solvent Purge Spray Gun Component type: Plural-Component Compatible material: Non-Flammable Foam, Polyurea Maximum fluid pressure: 3500 psi (241 bar) Maximum fluid working pressure: 3500 psi (242 bar) Maximum air inlet pressure: 130 psi (9 bar) minimum air inlet pressure: 80 psi (5.5 bar) Maximum fluid temperature: 200 °F (93 °C) Air inlet size: 1/4 in NPT Component A inlet size: 1/2 in UNF Component B inlet size: 9/16 in UNF Sound pressure level: 70 dB(A) Sound power level: 79.9 dB(A) Gun weight: 3.7 lb (1.68 kg) Overall length: 9 in (228 mm) Overall height: 8.1 in (206 mm) Overall width: 3.5 in (89 mm) For use with: Reactor Spray Foam and Coatings Equipment
Standards & Compliance
- Pressure Rating
- 3500 psi (241 bar) max fluid
- Temperature Range
- up to 200 °F (93 °C)
- HS Code
- 8424.20
Compatibility & Fitment
Fusion is Graco's plural-component impingement-mix spray-gun line for the Reactor proportioner range. Specialty series; Solvent Purge Spray Gun; Confirm orifice size, mix chamber/module and spray pattern match the material and output before ordering.
Product Documentation
More from Graco
Graco
Graco Round Fusion Air-Purge Gun with 03 Mix Chamber
248379
Graco
Graco Round Fusion Air-Purge Gun with 01 Mix Chamber
248377
Graco
Graco Fusion Air-Purge Gun, 0.038 in (0.96 mm) Orifice Size, 0.029 in (0.74 mm) Impingement Port & 8-10 in (203-254 mm) Flat Pattern Size
248381
Graco
Graco Fusion Air-Purge Gun, 0.024 in (0.61 mm) Orifice Size, 0.020 in (0.51 mm) Impingement Port and Low Flow 8-10 in (203-254 mm) Flat Pattern Size
248380
Graco
Graco Round Fusion Air-Purge Gun with 00 Mix Chamber
248376
Graco
Graco Round Auto Fusion Air-Purge Gun with 02 Mix Chamber
248378
Graco
Graco Manual 2K Dispense Gun
24R021
Graco
Graco Flat Pattern Fusion Air-Purge Gun with 0.024 in (0.61 mm) Orifice Size, 0.020 in (0.51 mm) Impingement Port and 8-10 in (203-254 mm) Pattern Size
247101
Catalogue entry last verified: 2026-08-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 248647?
- 248647 can be ordered from cballast.com as a Graco catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Graco product?
- The manufacturer part number is 248647.
- What is the HS code for 248647?
- The customs tariff (HS) code for 248647 is 8424.20.
- Who manufactures 248647?
- 248647 is a Graco product in the Tools & Workshop Consumables range.
- Is a datasheet available for 248647?
- Yes — the 248647 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 248647?
- The minimum order quantity is 1.
- Is 248647 available?
- Yes — 248647 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
