Graco TexSpray RTX 5500PX Texture Sprayer

Graco 17H581 TexSpray RTX 5500PX Texture Sprayer, part number 17H581. Graco TexSpray air-powered sprayer for spraying architectural texture, drywall, fireproofing and heavy-bodied finish materials. 100 psi maximum working pressure. Weight 163 lb. All values read from the Graco product page (17H581 on graco.com).

Brand

Graco Line: TexSpray Part number: 17H581 Amperage (A): 10, 16 Compatible material: Simulated Acoustic, Drywall Mud, Elastomeric Coating, Deck Coating, Cement-Based material Includes: Heavy-Duty Air Spray Trigger Gun, 1 1/4 in x 25 ft Heavy-Duty material/Air Hose, 3 mm Round Nozzle, 4 mm Round Nozzle, 6 mm Round Nozzle, 8 mm Round Nozzle, 10 mm Round Nozzle, 12 mm Round Nozzle, 4 mm WideTex Tip, 6 mm WideTex Tip, 8 mm WideTex Tip, 10 mm WideTex Tip, 12 mm WideTex Tip, XL WideTex Tip, WideTex Adapter material Application: Liquid Waterproofing Maximum Flow Rate (GPM): 5.5 Maximum Hose Length (ft): 100 Maximum Sound Pressure Level (dB(A)): 81.8 Maximum Working Pressure (MPa): 0.7 Maximum Working Pressure (psi): 100 minimum Generator Power (W): 7500 Model: TexSpray RTX Overall Height (in): 39.5 Overall Length (in): 33.75 Overall Width (in): 22.75 Power Source: Electric Product Series: Pro Exterior Series: 5500PX Type: Air-Powered Sprayer Voltage (V): 240 Weight (lb): 163 Wetted material: Brass, Aluminum, Plastic, Stainless Steel, Carbon Steel, Elastomer Maximum Flow Rate (L/min): 20.8 Maximum Hose Length (m): 30 Maximum Working Pressure (bar): 6.9 Maximum Working Pressure (kPa): 690 Overall Height (cm): 100 Overall Height (mm): 1000 Overall Length (cm): 86 Overall Length (mm): 860 Overall Width (cm): 58 Overall Width (mm): 580 Recommended Annual Usage: Up to 2500 gallons per year Weight (kg): 74

Pressure Rating

100 psi max working

HS Code

8424.20
