Function MICRO-4 Earth Fault Relay with Indicator Panel — Adjustable 30–300 mA, 1 s, Panel Included

The MICRO-4 is a compact earth fault relay with adjustable sensitivity from 30 to 300 mA and a 1 second tripping delay, running from a 230 V AC supply and providing a potential-free normally-open alarm contact. An earth fault relay measures the residual current — the difference between the current flowing out to a load and the current returning from it, which is only non-zero when some of it is escaping to earth — and signals rather than breaking the circuit itself, so it can be applied to circuits far larger than a self-contained RCD could switch and set for sensitivity independently of the device it drives. This is the version supplied WITH the indicator panel, which gives a visible earth fault indication at the board or door. The only difference between this item and the MICRO-4 listed without a panel is the panel itself — the relay, its 30 to 300 mA adjustable range and its 1 second delay are identical. Manufactured in Spain and supplied under the Function brand. Supplied by cBallast on quote-to-invoice terms; lead time and freight are quoted per RFQ against the destination Incoterm.

Manufacturer part number (MPN)

1661511

Sales unit

pcs

El-nummer (NO)

1661511

ETIM class

SC001444

Type of electric connection

Screw connection

Rated control supply voltage AC 50 Hz

230 V

Rated control supply voltage AC 60 Hz

230 V

Voltage type for actuating

AC

With detachable clamps

No

Function

For AC-current system

Rated voltage

230 V

Rated frequency

50–60 Hz

Indication of insulation value

No

Error registration possible

No

Number of contacts as normally open contact

1

Width

70 mm

Height

90 mm

Depth

70 mm

Country of origin

Spain

Device type

Earth fault relay

Sensitivity (IΔn)

30 – 300 mA, adjustable

Tripping delay

1 s

Alarm output

Potential-free normally-open contact

Indicator panel

Included

Model

MICRO-4

HS Code

8536.20

• 8433059162115
• El-nr 1661511
• MICRO-4
