Festo MS4-EM1 Inflation valve 3/2 - 1/4", Manual, MS4-EM1-1/4-S
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo MS4-EM1 Inflation valve 3/2. Air treatment (Technique / Pneumatics / Pneumatic Air Treatment). Principal data: thread 1/4", activation Manual, supplier type designation MS4-EM1-1/4-S. Supplied under manufacturer part number 541259, EAN 4052568090739, HS code 8481.20, country of origin Hungary.
Technical Specifications
- Design
- Rotary switching valve
- Type of actuation
- Manual
- Exhaust-air function
- Cannot be throttled
- Type of piloting
- Direct
- Symbol
- 00991670
- Valve function
- 3/2-way, double solenoid
- Operating pressure
- 0 ... 1.4 MPa (0 ... 14 bar)
- C value
- 9 l/sbar
- b value
- 0.39
- Standard nominal flow rate (standardised to DIN 1343)
- 2200 l/min
- Operating medium
- Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas
- Note on operating and pilot medium
- Lubricated operation possible (in which case lubricated operation will always be required)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Media temperature
- -10 ... 60 °C
- Ambient temperature
- -10 ... 60 °C
- Suitable for use with food
- See supplementary material information
- Type of mounting
- Either:; Inline installation; With accessories
- Mounting position
- Any
- Flow direction
- Non-reversible
- Product weight
- 210 g
- Pneumatic connection, port 1
- G1/4
- Pneumatic connection, port 2
- G1/4
- Pneumatic connection, port 3
- Not ducted
- Material seals
- TPE-U(PU)
- Material housing
- Die-cast aluminium
- EAN / GTIN
- 4052568090739
- Festo type code
- MS4-EM1-1/4-S
- Festo order number
- 541259
- Product type
- Air treatment
- Product group
- Pneumatics
- Thread
- 1/4"
- Activation
- Manual
- Working pressure
- 14 bar
- Temperature min
- -10 °C
- Temperature max
- 60 °C
- Carbon footprint (EPD)
- 5.0417 kg CO2e per pcs
- Country of origin
- Hungary
- Customs tariff code (EU CN)
- 84812090
- HS code
- 8481.20
- Manufacturer part number
- 541259
Standards & Compliance
- HS Code
- 8481.20
Cross References
- EAN 4052568090739
- MPN 541259
Product Documentation
