Festo LRS Pressure regulator Mini - 1/8", 0,5 - 7bar, LRS-1/8-D-7-O-I-MINI

Festo LRS Pressure regulator Mini. Air treatment (Technique / Pneumatics / Pneumatic Air Treatment). Principal data: thread 1/8", press area 0.5 to 7 bar, supplier type designation LRS-1/8-D-7-O-I-MINI. Supplied under manufacturer part number 194609, EAN 4052568153489, HS code 8481.10, country of origin Hungary.

Size

Mini

Series

D

Actuator lock

Rotary knob with integrated lock

Mounting position

Any

Design

Directly actuated diaphragm regulator

Controller function

Output pressure constant; With primary pressure compensation; With secondary exhausting; With return flow function

Symbol

00991559

Pressure gauge (ANALOG) or Pressure display (DIGITAL)

Prepared for G1/8

Operating pressure

0.1 ... 1.6 MPa (1 ... 16 bar)

Pressure regulation range

0.5 ... 7 bar

Max. pressure hysteresis

0.02 MPa (0.2 bar) (2.9 psi)

Standard nominal flow rate (standardised to DIN 1343)

1000 l/min

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas

Note on operating and pilot medium

Lubricated operation possible (in which case lubricated operation will always be required)

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Air purity class at output

Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas

Media temperature

-10 ... 60 °C

Ambient temperature

-10 ... 60 °C

Product weight

450 g

Type of mounting

With accessories

Pneumatic connection, port 1

G1/8

Pneumatic connection, port 2

G1/8

Material sub-base

Die-cast zinc

Material seals

NBR

Material housing

Die-cast zinc

EAN / GTIN

4052568153489

Festo type code

LRS-1/8-D-7-O-I-MINI

Festo order number

194609

Product type

Air treatment

Product group

Pneumatics

Thread

1/8"

Press Area

0.5 to 7 bar

Carbon footprint (EPD)

3.6584 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84811099

HS code

8481.10

Manufacturer part number

194609

HS Code

8481.10

• EAN 4052568153489
• MPN 194609
