Festo LRS Pressure regulator Mini - 1/4", 0,5 - 12bar, LRS-1/4-D-O-I-MINI
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo LRS Pressure regulator Mini. Air treatment (Technique / Pneumatics / Pneumatic Air Treatment). Principal data: thread 1/4", press area 0.5 to 12 bar, supplier type designation LRS-1/4-D-O-I-MINI. Supplied under manufacturer part number 194613, EAN 4052568153526, HS code 8481.10, country of origin Hungary.
Technical Specifications
- Size
- Mini
- Series
- D
- Actuator lock
- Rotary knob with integrated lock
- Mounting position
- Any
- Design
- Directly actuated diaphragm regulator
- Controller function
- Output pressure constant; With primary pressure compensation; With secondary exhausting; With return flow function
- Symbol
- 00991559
- Pressure gauge (ANALOG) or Pressure display (DIGITAL)
- Prepared for G1/8
- Operating pressure
- 0.1 ... 1.6 MPa (1 ... 16 bar)
- Pressure regulation range
- 0.5 ... 12 bar
- Max. pressure hysteresis
- 0.02 MPa (0.2 bar) (2.9 psi)
- Standard nominal flow rate (standardised to DIN 1343)
- 1500 l/min
- Operating medium
- Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas
- Note on operating and pilot medium
- Lubricated operation possible (in which case lubricated operation will always be required)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Air purity class at output
- Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas
- Media temperature
- -10 ... 60 °C
- Ambient temperature
- -10 ... 60 °C
- Product weight
- 450 g
- Type of mounting
- With accessories
- Pneumatic connection, port 1
- G1/4
- Pneumatic connection, port 2
- G1/4
- Material sub-base
- Die-cast zinc
- Material seals
- NBR
- Material housing
- Die-cast zinc
- EAN / GTIN
- 4052568153526
- Festo type code
- LRS-1/4-D-O-I-MINI
- Festo order number
- 194613
- Product type
- Air treatment
- Product group
- Pneumatics
- Thread
- 1/4"
- Press Area
- 0.5 to 12 bar
- Carbon footprint (EPD)
- 3.6437 kg CO2e per pcs
- Country of origin
- Hungary
- Customs tariff code (EU CN)
- 84811099
- HS code
- 8481.10
- Manufacturer part number
- 194613
Standards & Compliance
- HS Code
- 8481.10
Cross References
- EAN 4052568153526
- MPN 194613
Product Documentation
