Festo HEP Inflation valve Maxi - 1", Pneumatic, Spring, HEP, HEP-1-D-MAXI
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo HEP Inflation valve Maxi. Air treatment (Technique / Pneumatics / Pneumatic Air Treatment). Principal data: thread 1", activation Pneumatic, return Spring, series HEP. Supplied under manufacturer part number 193260, EAN 4052568153335, HS code 8481.20, country of origin Hungary.
Technical Specifications
- Design
- Piston gate valve Type of actuation: Pneumatic Sealing principle: Soft Exhaust-air function: Cannot be throttled Type of reset: Mechanical spring Symbol: 00991173 Valve function: 3/2-way, single solenoid, closed Operating pressure: 0 ... 1.6 MPa (0 ... 16 bar) Pilot pressure: 3 ... 16 bar C value: 27.6 l/sbar b value: 0.32 Standard nominal flow rate (standardised to DIN 1343): 6500 l/min Operating medium: Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas Note on operating and pilot medium: Lubricated operation possible (in which case lubricated operation will always be required) LABS (PWIS) conformity: VDMA24364-B1/B2-L Media temperature: -10 ... 60 °C Ambient temperature: -10 ... 60 °C Type of mounting: Inline installation; With accessories Mounting position: Any Flow direction: Non-reversible Product weight: 800 g Pneumatic connection, port 1: G1 Pneumatic connection, port 2: G1 Pneumatic connection, port 3: G3/8 Pilot air port 12: G1/8 Air purity class at output: Compressed air to ISO 8573-1:2010 [7:4:4]; Inert gas material seals: NBR material housing: Die-cast aluminium EAN / GTIN: 4052568153335 Festo type code: HEP-1-D-MAXI Festo order number: 193260 Product type: Air treatment Product group: Pneumatics Thread: 1" Activation: pneumatic Return: Spring Series: HEP Carbon footprint (EPD): 21.7862 kg CO2e per pcs Country of origin: Hungary Customs tariff code (EU CN): 84812090 HS code: 8481.20 Manufacturer part number: 193260
Standards & Compliance
- HS Code
- 8481.20
Cross References
- EAN 4052568153335
- MPN 193260
Product Documentation
More from Festo
Festo
Festo DSNU Round cylinder double-acting - 50mm, G1/4", 100mm, DSNU-50-100-PPV-A
196044
Festo
Festo VUVG-B14Z Solenoid Valve
8028236
Festo
Festo MHP1 Solenoid Valve - El, Spring, MHP1-M4H-3/2G-M3-TC
197012
Festo
Festo VUVG-L10 Solenoid Valve - M7", El, Spring, VUVG-L10-T32C-MZT-M7-1P3
574360
Festo
Festo LFR Filter controller Mini automatic - 3/8", 0,5 - 12bar, 5MY, LFR-3/8-D-5M-O-MINI-A
192622
Festo
Festo HUA Foot bracket - 50, HUA-50
157314
Festo
Festo QS Straight connection push-in composite - 12mm, 10mm, QS-12H-10
153044
Festo
Festo VABM-L1 Connection strip - 1/8", M5/M7, VABM-L1-10S-G18-3
566559
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 193260?
- 193260 can be ordered from cballast.com as a Festo catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Festo product?
- The manufacturer part number is 193260.
- What is the HS code for 193260?
- The customs tariff (HS) code for 193260 is 8481.20.
- Who manufactures 193260?
- 193260 is a Festo product in the Pneumatics range.
- Is a datasheet available for 193260?
- Yes — the 193260 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 193260?
- The minimum order quantity is 1.
- Is 193260 available?
- Yes — 193260 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
