Festo ADVU-16-25-P-A Compact cylinder
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo ADVU-16-25-P-A — Compact cylinder, pneumatic cylinders. stroke 25 mm; piston diameter 16 mm; operating pressure 0.12. 1 MPa (1.2. 10 bar; 17.4. 145 psi).
Technical Specifications
- Manufacturer part number (MPN)
- 156511
- Type code
- ADVU-16-25-P-A
- EAN / GTIN
- 4052568117771
- Product category
- Pneumatic cylinders
- Stroke
- 25 mm
- Piston diameter
- 16 mm
- Piston rod thread
- M4
- Cushioning
- Elastic cushioning rings/plates at both ends
- Mounting position
- Any
- Mode of operation
- Double-acting
- Piston-rod end
- Female thread
- Design
- Piston, Piston rod
- Position detection
- Via proximity switch
- Symbol
- 00991217
- Variants
- Piston rod at one end
- Operating pressure
- 0.12 ... 1 MPa (1.2 ... 10 bar; 17.4 ... 145 psi)
- Operating medium
- Compressed air to ISO 8573-1:2010 [7:4:4]
- Corrosion resistance class CRC
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -20 ... 80 °C
- Impact energy in end positions
- 0.1 J
- Theoretical force at 0.6 MPa (6 bar, 87 psi), return strok
- 90 N
- Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stro
- 121 N
- Moving mass for 0 mm stroke
- 12 g
- Additional moving mass per 10 mm stroke
- 4 g
- Basic weight for 0 mm stroke
- 89 g
- Additional weight per 10 mm stroke
- 15 g
- Type of mounting
- With through-hole, with accessories
- Pneumatic connection
- M5
- Material collar screws
- High-alloy stainless steel
- Material cover
- Wrought aluminium alloy
- Material dynamic seals
- NBR, TPE-U(PU)
- Material piston rod
- High-alloy stainless steel
- Material cylinder barrel
- Wrought aluminium alloy
- Product type
- Pneumatic ISO compact air cylinders
- Product group
- Pneumatics
- Port Size
- M5
- Carbon footprint (EPD)
- 1.7269 kg CO2e per pcs
- Country of origin
- Germany
- Customs tariff code (EU CN)
- 84123100
- HS code
- 8412.31
Standards & Compliance
- HS Code
- 8412.31
Cross References
- EAN 4052568117771
- MPN 156511
Product Documentation
More from Festo
Festo
Festo ADVU-50-30-A-P-A Compact cylinder
156640
Festo
Festo DSNU-25-320-PPS-A ISO cylinder
559292
Festo
Festo ADNGF-80-10-PPS-A Compact cylinder
574058
Festo
Festo AEVC Short stroke cylinder - 40mm, G1/8, 10mm, AEVC-40-10-A-P
188230
Festo
Festo ADNGF-80-25-PPS-A Compact cylinder
4052568221843
Festo
Festo VABB-B10-30-E-P3 Cover plate
8026336
Festo
Festo VUVG-B10-T32U-MZT-F-1P3 Solenoid valve
574365
Festo
Festo MSFW-230-50/60-OD Solenoid coil
