Festo MSFW-230-50/60-OD Solenoid coil
Pricing
Request a quote
We reply within 24 hours
Overview
Festo MSFW-230-50/60-OD Solenoid coil (part number 34422) is listed under Pneumatics / Pneumatic Valves. Type code: MSFW-230-50/60-OD; Product category: Solenoid coils; Mounting position: Any; Switching position indicator: No; Min. pick-up time: 10 ms; Duty cycle: 100%.
Technical Specifications
- Manufacturer part number (MPN)
- 34422
- Type code
- MSFW-230-50/60-OD
- EAN / GTIN
- 4052568023089
- Product category
- Solenoid coils
- Mounting position
- Any
- Switching position indicator
- No
- Min. pick-up time
- 10 ms
- Duty cycle
- 100%
- Power factor (cos phi)
- 0.7
- Characteristic coil data
- 230 V AC: 50/60 Hz, pick-up power 9.0 VA, holding power 7.0 VA
- Permissible frequency fluctuations
- +/-5%
- Permissible voltage fluctuations
- +/-10%
- CE mark (see declaration of conformity)
- To EU Low Voltage Directive
- UKCA marking (see declaration of conformity)
- To UK regulations for electrical equipment
- LABS (PWIS) conformity
- VDMA24364-C1-L
- Degree of protection
- IP65
- Ambient temperature
- -5 ... 40 °C
- Max. tightening torque for socket
- 0.4 Nm
- Product weight
- 55 g
- Electrical connection
- 3-pin, Plug pins with connection pattern to Festo standard for MSSD-F
- Type of mounting
- Via knurled nut
- Material solenoid coil
- Duroplast, Copper, Steel
- Material winding
- Copper
- Product type
- Pneumatic coils/cable connectors
- Product group
- Pneumatics
- Voltage
- 230 V
- Voltage type
- AC
- Carbon footprint (EPD)
- 0.3860 kg CO2e per pcs
- Country of origin
- Germany
- Customs tariff code (EU CN)
- 85059029
- HS code
- 8505.90
Standards & Compliance
- HS Code
- 8505.90
Cross References
- EAN 4052568023089
- MPN 34422
