Eaton
Mushroom pushbutton, IMP, Black/Start
Part numberM22-DP-W-X1EAN / GTIN4015082167264HS code8536.50
Control & Automation
Pushbuttons & Pilot Lights
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton M22-DP-W-X1 Mushroom actuator, white In, momentary.
Technical Specifications
- Manufacturer part number (MPN)
- M22-DP-W-X1
- EAN / GTIN
- 4015082167264
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Eaton catalogue number
- 216726
- Depth
- 37 mm
- Height
- 43 mm
- Width
- 37 mm
- Weight
- 0.016 kg
- Certifications
- CSA Class No.: 3211-03; UL Category Control No.: NKCR; CSA; UL; UL 508; CE; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; IEC/EN 60947; VDE 0660; UL File No.: E29184; CSA File No.: 012528; IEC/EN 60947-5; DNV; GL; LR
- Actuating force
- 5 N
- Actuator color
- White
- Actuator function
- Spring-return; Momentary
- Bezel color
- Titanium
- Bezel material
- Plastic
- Design
- Mushroom-shaped; Classical
- Fitted with
- Front ring
- Inscription
- Inscribed
- Lens type
- Round
- Unlocking method
- None
- Ambient operating temperature - max
- 70 °C
- Ambient storage temperature - max
- 80 °C
- Ambient operating temperature - min
- -25 °C
- Climatic proofing
- Damp heat, cyclic, to IEC 60068-2-30; Damp heat, constant, to IEC 60068-2-78
- Connection to SmartWire-DT
- With SWD-RMQ connections; Yes
- Degree of protection
- IP67/IP69K; NE
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 4015082167264
- SAP 1000013054
- Code 8103542
Product Documentation
Document preview: SOPPKNAPP, IMP, BLACK/START (M22-DP-W-X1) — Specification Data Sheet (OEM)
