Eaton
Joystick 4 Impulse Stillinger
Part numberM22-WJ4EAN / GTIN4015082794170HS code8538.90
Control & Automation
Pushbuttons & Pilot Lights
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton M22-WJ4 Joystick for 4 positions. IP66.
Technical Specifications
- Manufacturer part number (MPN)
- M22-WJ4
- EAN / GTIN
- 4015082794170
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Eaton catalogue number
- 279417
- Depth
- 100 mm
- Height
- 30 mm
- Width
- 30 mm
- Weight
- 0.028 kg
- Compliances
- CE Marked
- Certifications
- UL 508; IEC 60947-5; EN 60947-5; CSA Std. C22.2 No. 14-05; CSA Std. C22.2 No. 94-91; VDE; UL File No.: E29184; UL Category Control No.: NKCR; IEC/EN 60947-5; UL; VDE 0660; CE; CSA File No.: 012528; CSA-C22.2 No. 94-91; CSA Class No.: 3211-03; IEC/EN 60947; CSA-C22.2 No. 14-05; CSA
- Actuating force
- 5 N
- Actuator function
- In every position; Momentary
- Bezel color
- Titanium
- Bezel material
- Plastic
- Fitted with
- Front ring; Filament bulb (24 V); Plastic shaft; Retraction in 0-position
- Number of actuation directions
- 4
- Ambient operating temperature - max
- 70 °C
- Ambient operating temperature - min
- -25 °C
- Climatic proofing
- Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclic, to IEC 60068-2-30
- Connection to SmartWire-DT
- With SWD-RMQ connections; Yes
- Accessories
- Plastic shaft
- Degree of protection
- IP66; NEMA 4X, 13
- Lifespan, mechanical
- 100,000 Operations
- Mounting position
- As required
- Opening diameter
- 22.5 mm
- Operating frequency
- 2000 Operations/h
- Product Category
- RMQ-Titan
- Type
- Joystick
- Number of switch positions
- 1
- Centre mounting, hole diameter
- 22.5 mm
- With retraction in 0-position
- Yes
- Colour front ring
- Chrome
- Analogue output signal configurable
- No
- Coder
- No
- Material front ring
- Plastic
- With front ring
- Yes
- Locking in 0-position
- No
- Joy stick length
- 75 mm
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015082794170
- SAP 1000048881
- Code 8531806
Product Documentation
Document preview: JOYSTICK 4 IMPULS STILLINGER (M22-WJ4) — Specification Data Sheet (OEM)
