Residual current circuit breaker 40A 4P 100MA S/A
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton PFIM-40/4/01-S/A Residual current circuit breaker, 40A, Selective A-Type.
Technical Specifications
- Manufacturer part number (MPN)
- PFIM-40/4/01-S/A
- EAN / GTIN
- 4015082354671
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 3 pcs
- Eaton catalogue number
- 294299
- Depth
- 76 mm
- Height
- 80 mm
- Width
- 70 mm
- Weight
- 0.32 kg
- Compliances
- RoHS conform
- Certifications
- IEC/EN 61008
- Features
- Additional equipment possible; Selective protection
- Special features
- Maximum operating temperature is 60 °C: Starting at 40 °C, the max. permissible continuous current decreases by 2.5% for every 1 °C
- Amperage Rating
- 40 A
- Fault current rating
- 100 mA
- Number of poles
- Four-pole
- Ambient operating temperature - max
- 60 °C
- Ambient operating temperature - min
- -25 °C
- Equipment heat dissipation, current-dependent
- 8.8 W
- Heat dissipation capacity
- 0 W
- Heat dissipation per pole, current-dependent
- 0 W
- Rated operational current for specified heat dissipation (In)
- 40 A
- Static heat dissipation, non-current-dependent
- 0 W
- Admissible back-up fuse overload - max
- 25 A gG/gL
- Frequency rating
- 50 Hz
- Leakage current type
- A
- Pollution degree
- 2
- Rated impulse withstand voltage (Uimp)
- 4 kV
- Rated insulation voltage (Ui)
- 440 V
- Rated operational voltage (Ue) - max
- 400 V
- Rated short-time withstand current (Icw)
- 0.5 kA; 0 kA; 10 kA
- Surge current capacity
- 5 kA
- Built-in depth
- 70.5 mm
- Connectable conductor cross section (multi-wired) - max
- 16 mm²
- Connectable conductor cross section (multi-wired) - min
- 1.5 mm²
- Connectable conductor cross section (solid-core) - max
- 35 mm²
- Connectable conductor cross section (solid-core) - min
- 1.5 mm²
- Degree of protection
- IP20
- Mounting Method
- DIN-rail (DRA); DIN rail
- Width in number of modular spacings
- 4
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4015082354671
- SAP 1000005705
- Code 829644
Product Documentation
More from Eaton
Eaton
Residual current circuit breaker with overcurrent 16A 3P BA 30MA
PKPM3-16/3/B/003-A
Eaton
Eaton FAZ-C20/4 Miniature Circuit Breaker — 4P, Type C, 20 A, 15 kA
Eaton
iBox Distribution Board Package IT 50 A, 8 Circuits
I-48-4-DHS-PKP-50-3
Eaton
Eaton M22 Complete Rotary Switch 1NO 2-Position Latched
M22-WRK/K10
Eaton
10 A Bryteaktuator (CSAU-01/01-10)
Eaton
Residual current circuit breaker with overcurrent xDigital 16A B Type-F
300492
Eaton
Safety switch 3P 1NO1NC IN25A
P1-32/I2/SVB/HI11
Eaton
Eaton NZMH2-4-VX160/VAR Molded-Case Circuit Breaker 4-Pole 160A 150KA
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy PFIM-40/4/01-S/A?
- PFIM-40/4/01-S/A can be ordered from cballast.com as a Eaton catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Eaton product?
- The manufacturer part number is PFIM-40/4/01-S/A.
- What is the HS code for PFIM-40/4/01-S/A?
- The customs tariff (HS) code for PFIM-40/4/01-S/A is 8536.90.
- Who manufactures PFIM-40/4/01-S/A?
- PFIM-40/4/01-S/A is a Eaton product in the Electrical Components range.
- Is a datasheet available for PFIM-40/4/01-S/A?
- Yes — the PFIM-40/4/01-S/A datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for PFIM-40/4/01-S/A?
- The minimum order quantity is 1.
- Is PFIM-40/4/01-S/A available?
- Yes — PFIM-40/4/01-S/A is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
